DESCRIPTION
Demonstration circuit SCP-ADP5070-EVALZ is a dual out-
put DC-DC converter designed to create a dual polarity
regulated voltage for powering several signal chains. The
positive regulator provides 15V/1A of output while the
negative regulator delivers –15V/300mA.
Like all boards in the Signal Chain Power series, this board
is designed to be easily plugged into other SCP boards to
form a complete signal chain power system, enabling fast
evaluation of low power signal chains. To evaluate this
board, some universal SCP hardware is required, namely:
SCP-INPUT-EVALZ
SCP-OUTPUT-EVALZ
SCP-1X5BKOUT-EVALZ
SCP-THRUBRD-EVALZ
Table 1. Performance Summary
SYMBOL PARAMETER
V Max Input Voltage
IN(MAX)
V Max Output Voltage
OUT(MAX)
I Max Output Current
OUT(MAX)
BOARD IMAGE
DEMO MANUAL SCP-ADP5070-EVALZ
ADP5070 Dual Output Boost/Inverter
SCP-FILTER-EVALZ
SCP-1X2BKOUT-EVALZ
SCP-5X1-EVALZ
NOTES
Positive V
Negative V
Positive V
Negative V
Figure 1. SCP-ADP5070-EVALZ Board
SCP-ADP5070-EVALZ
Signal Chain Power
To properly evaluate SCP series demo boards, you will
need the SCP Configurator companion software. SCP
Configurator can help you choose the right board and to-
pology for your design.
Note that this Demo Manual does not cover details im-
portant to the operation and configuration regarding the
ADP5070. Please refer to the
complete description of the part.
Design files for this circuit board are available.
All registered trademarks and trademarks are property of their respective owners.
OUT
OUT
OUT
OUT
DEMO MANUAL
ADP5070 datasheet
MIN TYP MAX
15
39
–39
1
0.6
for a
UNITS
V
V
A
Rev. 0
