TRI2_BILEVEL_SLICE_EN, AFE Map, Address 0x1E, [5]
Function
TRI2_BILEVEL_SLI
CE_EN
0
1
TRI3_BILEVEL_SLICE_EN, AFE Map, Address 0x1F, [5]
Function
TRI3_BILEVEL_SLI
CE_EN
0
1
TRI4_BILEVEL_SLICE_EN, AFE Map, Address 0x20, [5]
Function
TRI4_BILEVEL_SLI
CE_EN
0
1
TRI5_BILEVEL_SLICE_EN, AFE Map, Address 0x21, [5]
Function
TRI5_BILEVEL_SLI
CE_EN
0
1
TRI6_BILEVEL_SLICE_EN, AFE Map, Address 0x22, [5]
Function
TRI6_BILEVEL_SLI
CE_EN
0
1
TRI7_BILEVEL_SLICE_EN, AFE Map, Address 0x23, [5]
Function
TRI7_BILEVEL_SLI
CE_EN
0
1
TRI8_BILEVEL_SLICE_EN, AFE Map, Address 0x24, [5]
Function
TRI8_BILEVEL_SLI
CE_EN
0
1
Rev. F August 2010
Description
Bilevel slicing mode
Trilevel slicing mode
Description
Bilevel slicing mode
Trilevel slicing mode
Description
Bilevel slicing mode
Trilevel slicing mode
Description
Bilevel slicing mode
Trilevel slicing mode
Description
Bilevel slicing mode
Trilevel slicing mode
Description
Bilevel slicing mode
Trilevel slicing mode
Description
Bilevel slicing mode
Trilevel slicing mode
80
