Analog Devices Advantiv ADV7604 Hardware Manual page 19

Pin Mnemonic
E1 DE
F1 HS
G1 P1
H1 P3
J1 DGND
K1 P4
L1 P6
M1 P8
N1 P9
P1 P10
R1 P12
T1 P14
U1 P16
V1 DGND
A2 RXD_2-
B2 RXD_2+
C2 TVDD
D2 RXB_5V
E2 CEC
F2 VS_FIELD
G2 P0
H2 P2
J2 DGND
K2 P5
L2 P7
Rev. F August 2010
Type Function
Digital Video DE (data enable) is a signal that indicates
Output active pixel data.
Digital Video HS is a horizontal synchronization output
Output signal in the CP and HDMI processor.
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Ground Ground
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Ground Ground.
HDMI Input Digital input channel 2 complement of port D
in the HDMI interface.
HDMI Input Digital input channel 2 true of port D in the
HDMI interface.
Power Terminator supply voltage (3.3 V)
HDMI Input 5 V detect pin for port B in the HDMI
interface.
Digital I/O Consumer electronic control channel.
Digital Video VS is a vertical synchronization output signal
Output in the CP and HDMI processor. FIELD is a
field synchronization output signal in all
interlaced video modes. VS or FIELD can be
configured for this pin.
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
Ground Ground.
Digital Video Video pixel output port.
Output
Digital Video Video pixel output port.
Output
19
ADV7604
