Register Bit Names
VDP_MAN_LINE_5_25[7:4]
VDP_MAN_LINE_6_26[7:4]
VDP_MAN_LINE_7_27[7:4]
VDP_MAN_LINE_8_28[7:4]
VDP_MAN_LINE_9_29[7:4]
VDP_MAN_LINE_10_30[7:4]
VDP_MAN_LINE_11_31[7:4]
VDP_MAN_LINE_12_32[7:4]
VDP_MAN_LINE_13_33[7:4]
VDP_MAN_LINE_14_34[7:4]
VDP_MAN_LINE_15_35[7:4]
VDP_MAN_LINE_16_36[7:4]
VDP_MAN_LINE_17_37[7:4]
VDP_MAN_LINE_18_38[7:4]
VDP_MAN_LINE_19_39[7:4]
VDP_MAN_LINE_20_40[7:4]
VDP_MAN_LINE_1_21[3:0]
VDP_MAN_LINE_2_22[3:0]
VDP_MAN_LINE_3_23[3:0]
VDP_MAN_LINE_4_24[3:0]
VDP_MAN_LINE_5_25[3:0]
VDP_MAN_LINE_6_26[3:0]
VDP_MAN_LINE_7_27[3:0]
VDP_MAN_LINE_8_28[3:0]
VDP_MAN_LINE_9_29[3:0]
VDP_MAN_LINE_10_30[3:0]
VDP_MAN_LINE_11_31[3:0]
VDP_MAN_LINE_12_32[3:0]
VDP_MAN_LINE_13_33[3:0]
VDP_MAN_LINE_14_34[3:0]
VDP_MAN_LINE_15_35[3:0]
VDP_MAN_LINE_16_36[3:0]
VDP_MAN_LINE_17_37[3:0]
VDP_MAN_LINE_18_38[3:0]
VDP_MAN_LINE_19_39[3:0]
VDP_MAN_LINE_20_40[3:0]
Rev. F August 2010
Register 525i 625i
Location
Line Numbers in which VBI Data is Inserted
0x68 10 10
0x69 11 11
0x6A 12 12
0x6B 13 13
0x6C 14 14
0x6D 15 15
0x6E 16 16
0x6F 17 17
0x70 18 18
0x71 19 19
0x72 20 20
0x73 21 21
0x74 22 22
0x75 23 23
0x76 24 24
25 + Full 25 + Full
0x77
Field Field
0x64 272 318
0x65 273 319
0x66 274 320
0x67 275 321
0x68 276 322
0x69 277 323
0x6A 278 324
0x6B 279 325
0x6C 280 326
0x6D 281 327
0x6E 282 328
0x6F 283 329
0x70 284 330
0x71 285 331
0x72 286 332
0x73 287 333
0x74 288 + 334
Full field
0x75 335
0x76 336
0x77 337 +
Full Field
325
ADV7604
1080i 525p, 625p,
720p
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
20 20
21 + Full
21
Field
22
23
24
25
569 26
570 27
571 28
572 29
573 30
574 31
575 32
576 33
577 34
578 35
579 36
580 37
581 38
582 39
583 40
584 + 41
Full Field
42
43
44
45 + Full
Frame
