Analog Devices Advantiv ADV7604 Hardware Manual page 85

TRI7_UPPER_SLICE_LEVEL[2:0], Sets the upper slice level for TRI7, AFE Map, Address
0x23, [4:2]
Function
TRI7_UPPER_SLICE
_LEVEL[2:0]
000
001
010
011
100
101
110
111
TRI8_UPPER_SLICE_LEVEL[2:0], Sets the upper slice level for TRI8, AFE Map, Address
0x24, [4:2]
Function
TRI8_UPPER_SLICE
_LEVEL[2:0]
000
001
010
011
100
101
110
111
6.6.9.2 Lower Slice Levels
TRI1_LOWER_SLICE_LEVEL[1:0], Sets the lower slice level for TRI1 in trilevel slice mode,
AFE Map, Address 0x1D, [1:0]
Function
TRI1_LOWER_SLIC
E_LEVEL[1:0]
00
01
10
11
Rev. F August 2010
Description
75 mV
225 mV
375 mV
525 mV
675 mV
825 mV
975 mV
1.125 V
Description
75 mV
225 mV
375 mV
525 mV
675 mV
825 mV
975 mV
1.125 V
Description
75 mV
225 mV
375 mV
525 mV
85
ADV7604
