7.18.2 General Control and Mode Information

The general control and mode information are specified in Byte 0 of the channel status. For more
information, refer to the IEC60958 standards.
CS_DATA[0], Consumer/Professional Application, HDMI Map, Address 0x36, [0]
Function
CS_DATA[0]
0
1
CS_DATA[1], PCM/non-PCM Audio Sample, HDMI Map, Address 0x36, [1]
Function
CS_DATA[1]
0
1
CS_DATA[2], Copyright, HDMI Map, Address 0x36, [2]
Function
CS_DATA[2]
0
1
CS_DATA[5:3], Emphasis, HDMI Map, Address 0x36, [5:3]
Function
1
CS_DATA[5:3]
000
001
1
Unspecified values are reserved
CS_DATA[7:6], Channel Status Mode, HDMI Map, Address 0x36, [7:6]
Function
1
CS_DATA[7:6]
00
1
Unspecified values are reserved
Rev. F August 2010
Description
Consumer application
Professional application
Description
Audio sample word represents linear PCM samples
Audio sample word used for other purposes
Description
Software for which copyright is asserted
Software for which no copyright is asserted
Description
Two audio channels without pre-emphasis
Two audio channels with 50/15 pre-emphasis
Description
Mode 0
