ESDP_PDN, IO Map, Address 0x0B, [2]
Function
ESDP_PDN
0
1
Important:
For optimum power consumption saving it is advised to power up the ESDP clocks only when the
part is in ESDP mode. This is done as follows:
• Set
ESPD_PDN
• Set
ESPD_PDN
3.2.4

ADC Power-Down Control

The ADV7604 contains three 12-bit ADCs (ADC 0, ADC 1, and ADC 2). It is possible to power
down each ADC individually, if required.
Note: In HDMI mode, all ADCs are powered down automatically unless
ADC_HDMI_SIMULT_MODE
PDN_ADC[0], AFE Map, Address 0x00, [0]
Function
PDN_ADC[0]
0
1
PDN_ADC[1], AFE Map, Address 0x00, [1]
Function
PDN_ADC[1]
0
1
PDN_ADC[2], AFE Map, Address 0x00, [2]
Function
PDN_ADC[2]
0
1
PDN_ADC[3], AFE Map, Address 0x00, [3]
Function
PDN_ADC[3]
0
1
Rev. F August 2010
Description
Powers down all the clocks running in the ESDP section
Powers up all the clocks running in the ESDP section
to 1 if ESDP_MODE
to 0 if ESDP_MODE
is set to 1.
Description
ADC 0 normal operation
Powers down ADC 0
Description
ADC 1 normal operation
Powers down ADC 1
Description
ADC 2 normal operation
Powers down ADC 2
Description
ADC 3 normal operation
Powers down ADC 3
is set to 0
is set to 1
