Analog Devices Advantiv ADV7604 Hardware Manual page 119

DCFIFO_KILL_NOT_LOCKED, HDMI Map, Address 0x1B, [3]
DCFIFO _ KILL_NOT_LOCKED
the video PLL is unlocked.
Function
DCFIFO_KILL_NOT_
LOCKED
0
1
DCFIFO_RESET_ON_LOCK, HDMI Map, Address 0x1B, [4]
The DCFIFO can be set to recenter itself automatically when the video PLL transitions from
unlocked to locked. Note that the video PLL transition does not necessarily indicate that the overall
system is stable.
Function
DCFIFO_RESET_ON_
LOCK
0
1
HDMI_DCFIFO_INTRQ_EN, IO Map, Address 0xC1, [7]
For debug purposes, the internal resynchronization pulse of the DCFIFO can be observed on the
INT2 pin by setting HDMI_DCFIFO_INTRQ_EN
selections for the INT2 pin. The only remaining control of INT2 when this bit is set high is to choose
the polarity of the interrupt.
Function
HDMI_DCFIFO_INTR
Q_EN
0
1
Rev. F August 2010
controls whether or not the output of the FIFO is set to zero when
Description
FIFO data is output regardless of video PLL lock status
FIFO output is zeroed if video PLL is unlocked
Description
DCFIFO does not react to video PLL unlock to lock transition
DCFIFO recenters on video PLL unlock to lock transition
Description
INT2 pin functions as configured per
DCFIFO resynchronization signal output on INT2 (overrides interrupt
selection controls for INT2)
119
high. This bit overrides any other interrupt
INT2_EN
ADV7604
