• The following HDMI subsections are active and functional when the ADV7604 runs in
simultaneous mode:
TMDS equalizer (refer to Section 7.6)
TMDS clock and data terminators (refer to Section 7.9)
TMDS clock detection circuitry (refer to Section 7.8)
TMDS clock measurement circuitry (refer to Section 7.10)
HDCP decryption engine (refer to Section 7.14.1)
HDMI synchronization filters II (refer to Section 7.15)
InfoFrame and packet extraction processor (refer to Section 7.19)
• The following HDMI subsections are not functional when the ADV7604 runs in simultaneous
mode:
HDMI sync filters I (refer to Section 7.15)
Audio processor (refer to Section 7.16)
Audio DPLL
• The following HDMI subsections are active and functional irrespective of the simultaneous
mode:
5V deglitch filter and detection circuitry (refer to Section 7.1)
EDID/Repeater controller (refer to Section 7.2)
CP_HDMI_SIMULTANEOUS_MODE, IO Map, Address 0x01, [7]
Function
CP_HDMI_SIMUL
TANEOUS_MODE
0
1
3.9

Pin Checker

A pin checker function allows the user to set the pins to specific signal levels values.
PIN_CHECKER_EN, IO Map, Address 0xD6, [0]
Function
PIN_CHECKER_EN
0
1
PIN_CHECKER_VAL[7:0], IO Map, Address 0xD7, [7:0]
Function
PIN_CHECKER_V
AL[7:0]
0
Rev. F August 2010
Description
Disables CP and HDMI simultaneous mode
Enables CP and HDMI simultaneous mode
Description
Disables pin checker function
Enables pin checker function
Description
Sets the signal level on output pins according to
PIN_CHECK_EN must be set high.

Table 2: Pin Checker Values Corresponding to Output Pins

Pin Name
P[35:32]
P[31:24]
Pin Checker Value
PIN_CHECKER_VAL[3:0]
PIN_CHECKER_VAL[7:0]
47
ADV7604
Table 2.
