Analog Devices Advantiv ADV7604 Hardware Manual page 399

Pin Mnemonic
P16 AVDD
R16 TRI2
T16 SYNC2
U16 AVDD
V16 AIN2
A17 TVDD
B17 RXA_2+
C17 RXA_1+
D17 RXA_0+
E17 RXA_C+
F17 TVDD
G17 TEST1
H17 REFN
J17 AGND
K17 AIN11
L17 SYNC4
M17 AGND
N17 AIN8
P17 SYNC3
R17 AGND
T17 AIN5
U17 AVDD
V17 AIN3
A18 DGND
B18 RXA_2-
C18 RXA_1-
D18 RXA_0-
E18 RXA_C-
F18 DGND
G18 TEST2
H18 REFP
J18 AGND
K18 AIN12
L18 AIN10
M18 AGND
N18 AIN9
P18 AIN7
R18 AGND
T18 AIN6
U18 AIN4
V18 AGND
Rev. F August 2010
Function
This pin is always connected to the Analog
supply voltage (1.8 V).
Float this pin.
Float this pin.
This pin is always connected to the Analog
supply voltage (1.8 V).
Float this pin.
This pin is always connected to the Terminator
supply voltage (3.3 V).
Float this pin.
Float this pin.
Float this pin.
Float this pin.
This pin is always connected to the Terminator
supply voltage (3.3 V).
Connect to ground via a 10k resistor
Follow the typical connection diagram for this
pin.
Connect this pin to ground
Float this pin.
Float this pin.
Connect this pin to ground
Float this pin.
Float this pin.
Connect this pin to ground
Float this pin.
This pin is always connected to the Analog
supply voltage (1.8 V).
Float this pin.
Connect this pin to ground
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Connect this pin to ground
Connect to ground via a 10k resistor
Follow the typical connection diagram for this
pin.
Connect this pin to ground
Float this pin.
Float this pin.
Connect this pin to ground.
Float this pin.
Float this pin.
Connect this pin to ground
Float this pin.
Float this pin.
Connect this pin to ground
399
ADV7604
