CH1_STDI_CONT Standard Identification Continuous Mode for channel 1 , CP Map, Address
0x86, [1]
Function
CH1_STDI_CONT
0
1
CH2_STDI_CONT Standard Identification Continuous Mode for channel 2 , CP Map, Address
0x42, [1]
Function
CH2_STDI_CONT
0
1
BYPASS_STDI1_LOCKING Standard Identification Real-Time Continuous Mode Control
for channel 1 , CP Map, Address 0xF5, [1]
Function
BYPASS_STDI1_
LOCKING
0
1
BYPASS_STDI2_LOCKING Standard Identification Real-Time Continuous Mode Control
for channel 2 , CP Map, Address 0xF5, [0]
Function
BYPASS_STDI2_
LOCKING
0
1
CH1_TRIG_STDI Trigger Standard Identification for channel 1 , CP Map, Address 0x86, [2]
Function
CH1_TRIG_STDI
0
1
Rev. F August 2010
Description
Channel 1 STDI block operates in single-shot mode (0 to 1 transition on
CH1_TRIG_STDI)
Channel 1 STDI block runs continuously
Description
Channel 2 STDI block operates in single-shot mode (0 to 1 transition on
CH2_TRIG_STDI)
Channel 2 STDI block runs continuously
Description
Updates timing readback values (BL, LCF, and LCVS) from STDI1 only
if they are locked (CH1_STDI_DVALID = 1)
Always updates timing readback values from STDI1 regardless of the
lock status
Description
Updates timing readback values (BL, LCF, and LCVS) from STDI2 only
if they are locked (CH1_STDI_DVALID = 2)
Always updates timing readback values from STDI1 regardless of the
lock status
Description
0 to 1 transition triggers channel 1 STDI measurements. Not self
clearing, must be reset by the user. 0 does nothing.
Not self clearing, must be reset by the user for next trigger. 1 restarts
channel 1 STDI measurements.
