ADM1060
those of the fault registers with the exception that the
ANYFLT bit cannot be masked. Setting a 1 in the error
mask register results in the equivalent bit in the fault reg-
ister always remaining at 0, regardless of whether there is a
fault on that function or not. The register and bit maps for
both the fault and error mask registers are shown below.

STATUS REGISTERS

TABLE 40. LIST OF STATUS REGISTERS
Hex Table Name
Addr.
D 8 41 U V S T A T
D 9 42 O V S T A T
D A 43 SFDSTAT
D B 44 G W S T A T
DE 45 PDOSTAT1
D F 46 PDOSTAT2
TABLE 41. BIT MAP FOR UVSTAT REGISTER D8H (POWER- ON DEFAULT 00H)
Bit
7
6
5
4
3
2
1
0
TABLE 42. BIT MAP FOR OVSTAT REGISTER D9H (POWER- ON DEFAULT 00H)
Bit
7
6
5
4
3
2
1
0
PRELIMINARY TECHNICAL DATA
Default
Power On Value
00h
00h
00h
00h
00h
00h
Name R/W
Reserved N/A
V P 4 U V R
V P 3 U V R
V P 2 U V R
V P 1 U V R
VHUV R
V B 2 U V R
V B 1 U V R
Name R/W
Reserved N/A
V P 4 O V R
V P 3 O V R
V P 2 O V R
V P 1 O V R
V H O V R
V B 2 O V R
V B 1 O V R
Description
Logic output of the UV comparator on each of the 7 SFD's
Logic output of the OV comparator on each of the 7 SFD's
Logic output (post Fault Type block) on each of the 7 SFD's
Logic state of the 4 GPI's and the Watchdog Fault Detector
Logic output of PDO's 1 to 8
Logic output of PDO 9
Description
Cannot be used
If high, then voltage on VP4 input is lower than the UV threshold
If high, then voltage on VP3 input is lower than the UV threshold
If high, then voltage on VP2 input is lower than the UV threshold
If high, then voltage on VP1 input is lower than the UV threshold
If high, then voltage on VH input is lower than the UV threshold
If high, then voltage on VB2 input is lower than the UV threshold
If high, then voltage on VB1 input is lower than the UV threshold
Description
Cannot be used
If high, then voltage on VP4 input is higher than the OV threshold
If high, then voltage on VP3 input is higher than the OV threshold
If high, then voltage on VP2 input is higher than the OV threshold
If high, then voltage on VP1 input is higher than the OV threshold
If high, then voltage on VH input is higher than the OV threshold
If high, then voltage on VB2 input is higher than the OV threshold
If high, then voltage on VB1 input is higher than the OV threshold
–32–
ADM1060 STATUS/FAULTS
REV. PrJ 11/02
