4 Primary Mode and Video Standard

Setting the primary mode and choosing a video standard are the most fundamental settings when
configuring the ADV7604.
There are three main modes of operation on the ADV7604.
• COMP
Analog-component video mode. This includes all video signals that arrive in a YPbPr (or
YUV) analog format. Typical examples are progressive and high definition video signals.
This mode is enabled by setting
• GR
Analog-graphic mode. This mode is intended for RGB input signals with high bandwidth.
This mode is enabled by setting
• HDMI
HDMI mode. In HDMI mode the ADV7604 can receive and decode HDMI or DVI data
throughout the DVI/HDMI receiver front end. Video data from the HDMI receiver is routed
to the DPP and CP blocks while audio data is available on the audio interface. This mode is
enabled by selecting either the HDMI (Graphics) primary mode or HDMI (Comp) primary
mode.
4.1

Primary Mode and Video Standard Controls

PRIM_MODE[3:0], IO Map, Address 0x01, [3:0]
VID_STD[5:0], IO Map, Address 0x00, [5:0]
PRIM_MODE[3:0]
Code Description
0000 Reserved
0001 COMP
(Component
Video)
e.g. YPrPb
Rev. F August 2010
PRIM_MODE[3:0]
PRIM_MODE[3:0]

Table 3: Primary Mode and Video Standard Selection

Processor Code
xxxxx
000000 Reserved
000001 Reserved
CP 000010 SD 2x1 525i
CP 000011 SD 2x1 625i
CP 000100 SD 4x1 525i
CP 000101 SD 4x1 625i
CP 000110 SD 2x2 525i
CP 000111 SD 2x2 625i
CP 001000 SD 4x2 525i
CP 001001 SD 4x2 625i
001010 Reserved
001011 Reserved
CP 001100 PR 2x1 525p
appropriately.
appropriately.
VID_STD[5:0]
Input Video Output
Resolution
Reserved Reserved
Reserved
Reserved
720 x 480
720 x 576
720 x 480
720 x 576
1440 x 480
1440 x 576
1440 x 480
1440 x 576
Reserved
Reserved
720 x 480
49
ADV7604
Comment
