8.4

Color Space Conversion Matrix

The ADV7604 features two 3x3 Color Space Converters (CSC); one in the DPP block (DPP CSC)
and the other in the CP block (CP CSC), as shown in
color space support, that is, they support formats such as RGB, YUV, YCrCb, and many other color
spaces. The DPP CSC and CP CSC are designed to run at speeds of up to 170 MHz.
The CP CSC also provides color controls for brightness, contrast, saturation, and hue.
1st Stage
Decimation
Filter
The configuration of the color space conversion using the DPP and CP CSC blocks and a description
of the adjustable register bits are provided in
Rev. F August 2010
Data Pre Processor
(DPP)
DPP Color Space
Conversion Matrix
(DPP CSC)

Figure 61: DPP/CP CSC Block Diagram

Figure

Figure 62: Configuring DPP/CP CSC Blocks

Figure 61. The two CSCs provide any-to-any
Component Processor
2nd Stage
Decimation
Filter
62.
202
(CP)
CP Color Space
Conversion Matrix
(CP CSC)
ADV7604
