DEF_COL_CHA/B/C[7:0] Manual Default Color Channel A/B/C , CP Map, Address 0xC0,

[7:0]; Address 0xC1, [7:0]; Address 0xC2, [7:0]

The three parameters DEF_COL_CHA[7:0], DEF_COL_CHB[7:0], and DEF_COL_CHC[7:0]

allow the user to specify their own default values.

CP_DEF_COL_MAN_VAL

for more information on the automatic values.

DEF_COL_CHA[7:0]

DEF_COL_CHB[7:0]

DEF_COL_CHC[7:0]

Rev. F August 2010

must be set high for the three parameters to be used.

Manual default color for channel A

Manual default color for channel B

Manual default color for channel C
