The name of the field. In this example the field is
called REFERENCE_TRIM and is 3 bit long.
REFERENCE_TRIM[2:0], ADC Reference Trim, AFE Map, Address 0x0F, [7:5]
ADC Reference Trim is used to adjust the ADC full range scale. The default value for ADC
Reference Trim is 3b000. This must be changed to 3b100 for proper operation.
Function
REFERENCE_TRIM[2:0]
xxx
000
001
010
011
100
101
110
111
Values the field can be set to
or take. These values are in
binary format if not preceded
by '0x' and in hexadecimal
format if preceded by '0x'.
1.8

References

HDMI Licensing and LLC, High-Definition Multimedia Interface, Revision 1.3a, November 10,
2006
Digital Content Protection (DCP) LLC, High-bandwidth Digital Content Protection System,
Revision 1.3, December 21, 2006
CEA, CEA-861-D, A DTV Profile for Uncompressed High Speed Digital Interfaces, Revision D,
July 18, 2006
IUT, ITU-R BT.656-4, Interface for Digital Component Video Signals in 525-Line and 625-Line
Television Systems Operating at the 4:2:2 Level of Recommendation ITU-R BT.601, February 1998
IUT, ITU-R BT.601-5 Studio encoding parameters of digital television for standard 4:3 and
widescreen 16:9 aspect ratios, October 1995
IUT, ITU-R BT.709-5 Parameter values for the HDTV standards for production and international
programme exchange, April 2002
Rev. F August 2010
Short function
description
of the field
Description
Adjust the ADC full-range scale.
1.0 V
1.1 V
1.2 V
1.3 V
1.4 V (recommended setting)
Reserved
Reserved
Reserved
Default value
Function of the field for each
indicated by
value the field can take or be
set to. Values are in binary
format.

Figure 1: Field Description Format

11
I2C location of the
field in big endian
format (MSB first,
LAST last)
Detailed
description
of the field
ADV7604
