Bits 31: 16 Reserved, must be kept at reset value.
Bits 15: 0 TSC: Timestamp Counter
Note:
A "wrap around" is a change of the Timestamp Counter value from non-0 to 0 that is not
caused by write access to TSCV.
43.4.10
FDCAN timeout counter configuration register (FDCAN_TOCC)
Address offset: 0x0028
Reset value: 0xFFFF 0000
31
30
29
rw
rw
rw
15
14
13
Res.
Res.
Res.
Res.
Bits 31: 16 TOP: Timeout Period
Bits 15: 3 Reserved, must be kept at reset value.
Bits 2: 1 TOS: Timeout Select
Bit 0 ETOC: Enable Timeout Counter
For more details see
43.4.11
FDCAN timeout counter value register (FDCAN_TOCV)
Address offset: 0x002C
Reset value: 0x0000 FFFF
The internal/external Timestamp Counter value is captured on start of frame (both Rx and
Tx). When TSCC[TSS] = '01', the Timestamp Counter is incremented in multiples of CAN
bit times [1 ... 16] depending on the configuration of TSCC[TCP]. A wrap around sets
interrupt flag IR[TSW]. Write access resets the counter to 0. When TSCC.TSS = 10, TSC
reflects the external Timestamp Counter value. A write access has no impact.
28
27
26
25
rw
rw
rw
rw
12
11
10
9
Res.
Res.
Res.
Start value of the Timeout Counter (down-counter). Configures the Timeout Period.
When operating in Continuous mode, a write to TOCV presets the counter to the value
configured by TOCC[TOP] and continues down-counting. When the Timeout Counter is
controlled by one of the FIFOs, an empty FIFO presets the counter to the value configured
by TOCC[TOP]. Down-counting is started when the first FIFO element is stored.
00: Continuous operation
01: Timeout controlled by Tx Event FIFO
10: Timeout controlled by Rx FIFO 0
11: Timeout controlled by Rx FIFO 1
These are protected write (P) bits, write access is possible only when the bit 1 [CCE] and
bit 0 [INIT] of CCCR register are set to 1.
0: Timeout Counter disabled
1: Timeout Counter enabled
This is a protected write (P) bit, write access is possible only when the bit 1 [CCE] and bit
0 [INIT] of CCCR register are set to 1.
Timeout
counter.
FD controller area network (FDCAN)
24
23
22
TOP[15:0]
rw
rw
rw
8
7
6
Res.
Res.
Res.
RM0440 Rev 1
21
20
19
18
rw
rw
rw
rw
5
4
3
2
Res.
Res.
Res.
TOS[1:0]
rw
17
16
rw
rw
1
0
ETOC
rw
rw
1939/2083
