Debug support (DBG)
46.4.1 SWJ debug port pins
Five pins are used as outputs from the STM32G4 Series for the SWJ-DP as alternate
functions of general-purpose I/Os. These pins are available on all packages.
SWJ-DP pin name
JTMS/SWDIO
JTCK/SWCLK
JTDI
JTDO/TRACESWO
NJTRST
46.4.2 Flexible SWJ-DP pin assignment
After RESET (SYSRESETn or PORESETn), all five pins used for the SWJ-DP are assigned
as dedicated pins immediately usable by the debugger host (note that the trace outputs are
not assigned except if explicitly programmed by the debugger host).
However, the STM32G4 Series MCUs offer the possibility of disabling some or all of the
SWJ-DP ports, and therefore the possibility of releasing (in gray in the table below) the
associated pins for general-purpose I/O (GPIO) usage, except for NJTRST that can be left
disconnected but cannot be used as general purpose GPIO without loosing debugger
connection. For more details on how to disable SWJ-DP port pins, please refer to
Section 8.3.2: I/O pin alternate function multiplexer and
Full SWJ (JTAG-DP + SW-DP) - Reset State
Full SWJ (JTAG-DP + SW-DP) but without NJTRST
JTAG-DP disabled and SW-DP enabled
JTAG-DP disabled and SW-DP disabled
2044/2083

Table 424. SWJ debug port pins

JTAG debug port
Type Description
JTAG Test Mode
I
Selection
I JTAG Test Clock
I JTAG Test Data Input
O JTAG Test Data Output
I JTAG Test nReset

Table 425. Flexible SWJ-DP pin assignment

Available debug ports
RM0440 Rev 1
SW debug port
Type Debug assignment
Serial Wire Data
IO
Input/Output
I Serial Wire Clock
- -
TRACESWO if
- asynchronous trace is
enabled
- -
mapping.
SWJ IO pin assigned
PA13 / PA14 /
PA15 /
JTMS/ JTCK/
JTDI
SWDIO SWCLK
X X X
X X X
X X
Released
RM0440
Pin
assign
ment
PA13
PA14
PA15
PB3
PB4
PB3 / PB4/
JTDO NJTRST
X X
X
