12.6.11 JPEG COMPRESSION FLOW
This is a pseudo instruction set that indicates the write or read on specific registers. It is assumed that the
Huffman and quantization tables were written already.
// JPEG encoder initialization
Write SW_RESET
Write JPGCLKCON
Write JPGCMOD
Write JPGMOD
Write JPGDRI
Write QTBL
tables.
Write JPGY_U
Write JPGY_L
Write JPGX_U
Write JPGX_L
Write IMGADR
Write JPGADR
Write COEF1
Write COEF2
Write COEF3
// Encoding start.
Write JSTART
// After interrupt is detected, clear the pending register
Read JPGCNT_U
Read JPGCNT_M
Read JPGCNT_L
Read JPGINTST
Write JPGCOM
Read JPGOPR
0x1
0x1
0x20 // Mode selection
0x1 // Encoding and YCbCr4:2:2
0x0 // No DRI if 0. Set an appropriate value.
0x0 // Choose the appropriate table index for Huffman & Quantization
0x0 // Vertical resolution Upper byte
0x0 // Vertical resolution Lower byte
0x0 // Horizontal resolution Upper byte
0x0 // Horizontal resolution Lower byte
0x1000_0000 // Address for an image to compress
0x1001_0000 // Address for the compressed JPEG file
0x4D_971E // Color converter coefficients
0x2c_5783 // Color converter coefficients
0x83_6e13 // Color converter coefficients
0x1
// Read the file size in bytes
// Read the file size in bytes
// Read the file size in bytes
// It must be read 0x40.
0x4 // Clear interrupt
// It must be read zero.
