USB on-the-go full-speed (OTG_FS)

OTG reset register (OTG_GRSTCTL)

Address offset: 0x10

Reset value: 0x8000 0000

The application uses this register to reset various hardware features inside the core.

Bit 31 AHBIDL: AHB master idle

Indicates that the AHB master state machine is in the Idle condition.

Note: Accessible in both device and host modes.

Bits 30:11 Reserved, must be kept at reset value.

Bits 10:6 TXFNUM[4:0]: Tx FIFO number

This is the FIFO number that must be flushed using the Tx FIFO Flush bit. This field must not

be changed until the core clears the Tx FIFO Flush bit.

00010: Tx FIFO 2 flush in device mode

01111: Tx FIFO 15 flush in device mode

10000: Flush all the transmit FIFOs in device or host mode.

Note: Accessible in both device and host modes.

Bit 5 TXFFLSH: Tx FIFO flush

This bit selectively flushes a single or all transmit FIFOs, but cannot do so if the core is in the

midst of a transaction.

The application must write this bit only after checking that the core is neither writing to the Tx

FIFO nor reading from the Tx FIFO. Verify using these registers:

Read—NAK Effective interrupt ensures the core is not reading from the FIFO

Write—AHBIDL bit in OTG_GRSTCTL ensures the core is not writing anything to the FIFO.

Flushing is normally recommended when FIFOs are reconfigured. FIFO flushing is also

recommended during device endpoint disable. The application must wait until the core clears

this bit before performing any operations. This bit takes eight clocks to clear, using the slower

clock of phy_clk or hclk.

Note: Accessible in both device and host modes.

Non-periodic Tx FIFO flush in host mode

Tx FIFO 0 flush in device mode

Periodic Tx FIFO flush in host mode

Tx FIFO 1 flush in device mode

RM0432 Rev 6

FCRST PSRST CSRST
