CTI device type identifier register (CTI_DEVTYPER)
Address offset: 0xFCC
Reset value: 0x0000 0014
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 SUBTYPE[3:0]: sub-classification
0x1: Indicates that this component is a cross-triggering component.
Bits 3:0 MAJORTYPE[3:0]: major classification
0x4: Indicates that this component allows a debugger to control other components in a
CoreSight™ SoC-400 system.
CTI CoreSight peripheral identity register 4 (CTI_PIDR4)
Address offset: 0xFD0
Reset value: 0x0000 0004
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 F4KCOUNT[3:0]: register file size
0x0: The register file occupies a single 4-Kbyte region
Bits 3:0 JEP106CON[3:0]: JEP106 continuation code
0x4: Arm
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
Res.
Res.
Res.
Res.
®
JEDEC code
RM0453 Rev 2
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
SUBTYPE[3:0]
r
r
r
r
23
22
21
20
Res.
Res.
Res.
Res.
7
6
5
4
F4KCOUNT[3:0]
r
r
r
r
Debug support (DBG)
19
18
17
16
Res.
Res.
Res.
Res.
3
2
1
0
MAJORTYPE[3:0]
r
r
r
r
19
18
17
16
Res.
Res.
Res.
Res.
3
2
1
0
JEP106CON[3:0]
r
r
r
r
1369/1454
1441
