Debug support (DBG)
38.10.4 ITM trace control register (ITM_TCR)
Address offset: 0xE80
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
Res. Res. Res. Res.
Bits 31:24 Reserved, must be kept at reset value.
Bit 23 BUSY: Indicates whether the ITM is currently processing events (read only).
0: Not busy
1: Busy
Bits 22:16 TRACEBUSID[6:0]: identifier for multi-source trace stream formatting
If multi-source trace is in use, the debugger must write a non-zero value to this field.
Note: Different IDs must be used for each trace source in the system.
Bits 15:10 Reserved, must be kept at reset value.
Bits 9:8 TSPRESCALE[1:0]: local timestamp prescaler
Used with the trace packet reference clock. The possible values are:
0x0: No prescaling
0x1: Divides by 4.
0x2: Divides by 16.
0x3: Divides by 64.
Bits 7:5 Reserved, must be kept at reset value.
Bit 4 SWOENA: enable for asynchronous clocking of the timestamp counter (read only)
0: Timestamp counter uses processor clock
Bit 3 TXENA: Enables forwarding of hardware event packets from the DWT unit to the trace port.
0: Disabled
1: Enabled
Bit 2 SYNCENA: enable for packet transmission synchronization
Note: The debugger setting this bit must also configure the DWT_CTRLR register SYNCTAP
0: Disabled
1: Enabled
Bit 1 TSENA: enable for local timestamp generation
0: Disabled
1: Enabled
Bit 0 ITMENA: ITM enable
0: Disabled
1: Enabled
1394/1454
27 26 25 24
Res. Res. Res. Res.
11 10 9 8
Res. Res.
TSPRESCALE[1:0]
rw rw
field in the DWT for the correct synchronization speed.
RM0453 Rev 2
23 22 21 20
BUSY
rw rw rw rw
7 6 5 4
Res. Res. Res.
SWOENA TXENA SYNCENA TSENA ITMENA
r
19 18 17
TRACEBUSID[6:0]
rw rw rw
3 2 1
rw rw rw
RM0453
16
rw
0
rw
