Direct memory access controller (DMA)
11.5 DMA interrupts
An interrupt can be generated on a half transfer, transfer complete or transfer error for each
DMA channel x. Separate interrupt enable bits are available for flexibility.
Interrupt request
Half transfer on channel x
Transfer complete on channel x
Channel x interrupt
Transfer error on channel x
Half transfer or transfer complete or transfer error on channel x
11.6 DMA registers
Refer to
The DMA registers have to be accessed by words (32-bit).
11.6.1 DMA interrupt status register (DMA_ISR)
Address offset: 0x00
Reset value: 0x0000 0000
This register may mix privileged and unprivileged information, depending on the privileged
mode of each channel (PRIV bit of the DMA_CCRx register). A privileged software can read
the full interrupt status. An unprivileged software is restricted to read the status of
unprivileged channel(s), other privileged bit fields returning zero.
Every status bit is cleared by hardware when the software sets the corresponding clear bit
or the corresponding global clear bit CGIFx, in the DMA_IFCR register, provided that, if the
channel x is in privileged mode, then the software access to DMA_IFCR is also privileged.
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
TEIF4 HTIF4 TCIF4 GIF4
r r r
Bits 31:28 Reserved, must be kept at reset value.
Bit 27 TEIF7: transfer error (TE) flag for channel 7
0: no TE event
1: a TE event occurred
Bit 26 HTIF7: half transfer (HT) flag for channel 7
0: no HT event
1: a HT event occurred
370/1306

Table 69. DMA interrupt requests

Interrupt event
Section 1.2 for a list of abbreviations used in register descriptions.
27 26 25
TEIF7 HTIF7 TCIF7
r r r
11 10 9
TEIF3 HTIF3 TCIF3
r r r r
24 23 22
GIF7 TEIF6 HTIF6 TCIF6
r r r
8 7 6
GIF3 TEIF2 HTIF2 TCIF2
r r r
RM0461 Rev 5
Event flag
HTIFx
TCIFx
TEIFx
GIFx
21 20 19 18
GIF6 TEIF5 HTIF5
r r r r
5 4 3 2
GIF2 TEIF1 HTIF1
r r r r
RM0461
Interrupt
enable bit
HTIEx
TCIEx
TEIEx
-
17 16
TCIF5 GIF5
r r
1 0
TCIF1 GIF1
r r
