RM0461
21.4.16 AES DMA interface
The AES peripheral provides an interface to connect to the DMA (direct memory access)
controller. The DMA operation is controlled through the AES_CR register.
Data input using DMA
Setting the DMAINEN bit of the AES_CR register enables DMA writing into AES. The AES
peripheral then initiates a DMA request during the input phase each time it requires to write
a 128-bit block (quadruple word) to the AES_DINR register, as shown in
Note: According to the algorithm and the mode selected, special padding / ciphertext stealing
might be required. For example, in case of AES GCM encryption or AES CCM decryption, a
DMA transfer must not include the last block. For details, refer to
procedure to perform a cipher

Figure 111. DMA transfer of a 128-bit data block during input phase

Word3
DIN[127:96]
D127
MSB
DMA
DMA req N
single write
1
(No swapping)
1
I127
MSB
1 4
Order of write to AES_DINR
Data output using DMA
Setting the DMAOUTEN bit of the AES_CR register enables DMA reading from AES. The
AES peripheral then initiates a DMA request during the Output phase each time it requires
to read a 128-bit block (quadruple word) to the AES_DINR register, as shown in
Note: According to the message size, extra bytes might need to be discarded by application in the
last block.
operation.
Chronological order
Increasing address
Memory accessed through DMA
Word2
DIN[95:64]
D96 D95
DMA
DMA req N+1
single write
2
2
AES core input buffer
I96 I95
Word1
DIN[63:32]
D64 D63
DMA
DMA req N+2
single write
3
AES_DINR
3
I64 I63
RM0461 Rev 5
AES hardware accelerator (AES)
Figure
Section 21.4.4: AES
Word0
DIN[31:0]
D32 D31
DMA
DMA req N+3
single write
4
4
I32 I31
111.
D0
LSB
I0
LSB
MSv42160V1
Figure 112.
577/1306
