11.4 DMA functional description
11.4.1 DMA block diagram
The DMA block diagram is shown in
dma1_req [1..7]
dma1_ack [1..7]
dma1_priv[1..7]
dma2_req [1..7]
dma2_ack [1..7]
dma2_priv[1..7]
Figure 36.

Figure 36. DMA block diagram

DMA1
Ch 1
Ch 2
Ch 7
Arbiter
Interrupt
interface
dma1_it[1..7]
DMA2
Ch 1
Ch 2
Ch 7
Arbiter
Interrupt
interface
dma2_it[1..7]
RM0461 Rev 5
Direct memory access controller (DMA)
AHB master interface
AHB slave interface
AHB master interface
AHB slave interface
MSv61545V1
361/1306
