Reset and clock control (RCC)
6.4.17 RCC AHB3 peripheral clock enable register (RCC_AHB3ENR)
Address offset: 0x050
Reset value: 0x0208 0000
Access: no wait state, word, half-word and byte access
Note: When the peripheral clock is not active, the peripheral registers read or write access is not
supported.
31 30 29
Res. Res. Res.
15 14 13
Res. Res. Res.
Bits 31:26 Reserved, must be kept at reset value.
Bit 25 FLASHEN: Flash memory interface clock enable
Bits 24:20 Reserved, must be kept at reset value.
Bit 19 HSEMEN: HSEM clock enable
Bit 18 RNGEN: true RNG clocks enable
Bit 17 AESEN: AES accelerator clock enable
Bit 16 PKAEN: PKA accelerator clock enable
Bits 15:0 Reserved, must be kept at reset value.
