General-purpose I/Os (GPIO)
8.4.8
GPIOx configuration lock register (GPIOx_LCKR) (x = A to B)
Address offset: Block A: 0x001C
Address offset: Block B: 0x041C
Reset value: 0x0000 0000
This register is used to lock the configuration of the port bits when a correct write sequence
is applied to bit 16 (LCKK). The value of bits [15:0] is used to lock the configuration of the
GPIO. During the write sequence, the value of LCKR[15:0] must not change. When the lock
sequence has been applied on a port bit, the value of this port bit can no longer be modified
until the next MCU reset or peripheral reset.
Note:
A specific write sequence is used to write to GPIOx_LCKR. Only word access (32-bit long)
is allowed during this locking sequence.
Each lock bit freezes a specific configuration register (control and alternate function
registers).
31
30
29
Res.
Res.
Res.
15
14
13
LCK15
LCK14
LCK13
LCK12
rw
rw
rw
Bits 31:17 Reserved, must be kept at reset value.
Bit 16 LCKK: Lock key
Note: During the LOCK key write sequence, the value of LCK[15:0] must not change.
Bits 15:0 LCKy: Port Px[15:0] lock configuration (y = 15 to 0)
322/1306
28
27
26
25
Res.
Res.
Res.
Res.
12
11
10
9
LCK11
LCK10
LCK9
rw
rw
rw
rw
This bit can be read any time. It can only be modified using the lock key write sequence.
0: Port configuration lock key not active
1: Port configuration lock key active. The GPIOx_LCKR register is locked until the next MCU
reset or peripheral reset.
LOCK key write sequence:
WR LCKR[16] = 1 + LCKR[15:0]
WR LCKR[16] = 0 + LCKR[15:0]
WR LCKR[16] = 1 + LCKR[15:0]
RD LCKR
RD LCKR[16] = 1 (This read operation is optional but it confirms that the lock is active.)
Any error in the lock sequence aborts the lock.
After the first lock sequence on any bit of the port, any read access on the LCKK bit
returns 1 until the next MCU reset or peripheral reset.
These bits are read/write but can only be written when the LCKK bit is 0.
0: Port Pxy configuration not locked
1: Port Pxy configuration locked
24
23
22
Res.
Res.
Res.
8
7
6
LCK8
LCK7
LCK6
rw
rw
rw
RM0461 Rev 5
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
LCK5
LCK4
LCK3
LCK2
rw
rw
rw
rw
RM0461
17
16
Res.
LCKK
rw
1
0
LCK1
LCK0
rw
rw
