Reset and clock control (RCC)
The LSE crystal is switched on and off using the LSEON bit in the
control register
runtime using the LSEDRV[1:0] bits in the
(RCC_BDCR)
on one side and low-power-consumption on the other side. The LSE drive can be decreased
to the lower drive capability (LSEDRV = 0) when the LSE is on. However, once LSEDRV is
selected, the drive capability can not be increased if LSEON = 1.
The LSERDY flag in the
whether the LSE crystal is stable or not. At startup, the LSE crystal output clock signal is not
released until this bit is set by hardware. An interrupt can be generated if enabled in the
RCC clock interrupt enable register
When enabled and ready the LSE clock can directly be used by the RTC. To be able to use
the clocks by other peripherals (LPTIMx, TIMx, USARTx, LPUARTx, system LSCO, MCO,
MSI PLL mode), the LSE system clock must be enabled with the LSESYSEN bit in the
Backup domain control register
is enabled, the LSE clock is used by the LSECSS and is available on the LSCO. A
LSESYSRDY flag is provided in the
indicate when LSE system clock is ready (due clock synchronization) after having been
enabled by the LSESYSEN.
External source (LSE bypass)
In this mode, an external clock source must be provided. It can have a frequency of up to
1 MHz. This mode is selected by setting the LSEBYP and LSEON bits in the
domain control register
with ~50 % duty cycle must drive the OSC32_IN pin while the OSC32_OUT pin can be used
as GPIO (see
6.2.6 LSI clock
The LSI RC acts as a low-power clock source that can be kept running in Stop and Standby
modes for the independent watchdog (IWDG) and RTC. The clock frequency is ~32 kHz or
can be divided by 128 (~250 Hz) using LSIPRE. For more details, refer to the electrical
characteristics section of the datasheets.
240/1306

Figure 24. LSE clock sources
