Real-time clock (RTC)
30.6.6 RTC wakeup timer register (RTC_WUTR)
This register can be written only when WUTWF is set to 1 in RTC_ICSR.
Address offset: 0x14
Backup domain reset value: 0x0000 FFFF
System reset: not affected
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:16 WUTOCLR[15:0]: Wakeup auto-reload output clear value
Bits 15:0 WUT[15:0]: Wakeup auto-reload value bits
30.6.7 RTC control register (RTC_CR)
This register is write protected. The write access procedure is described in
write protection on page
Address offset: 0x18
Backup domain reset value: 0x0000 0000
System reset: not affected
31 30 29
TAMP TAMP
OUT2
ALRM_ ALRM_ Res.
EN
TYPE PU
rw rw rw
15 14 13
ALRB ALRA
TSIE WUTIE
IE
rw rw rw
912/1306
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
When WUTOCLR[15:0] is different from 0x0000, WUTF is set by hardware when the auto-
reload down-counter reaches 0 and is cleared by hardware when the auto-reload
downcounter reaches WUTOCLR[15:0].
When WUTOCLR[15:0] = 0x0000, WUTF is set by hardware when the WUT down-counter
reaches 0 and is cleared by software.
When the wakeup timer is enabled (WUTE set to 1), the WUTF flag is set every
(WUT[15:0] + 1) ck_wut cycles. The ck_wut period is selected through WUCKSEL[2:0] bits
of the RTC_CR register.
When WUCKSEL[2] = 1, the wakeup timer becomes 17-bits and WUCKSEL[1] effectively
becomes WUT[16] the most-significant bit to be reloaded into the timer.
The first assertion of WUTF occurs between WUT and (WUT + 2) ck_wut cycles after WUTE
is set. Setting WUT[15:0] to 0x0000 with WUCKSEL[2:0] = 011 (RTCCLK/2) is forbidden.
896.
28 27 26 25
TAMP TAMP
Res.
OE TS
rw rw
12 11 10 9
TSE WUTE ALRBE ALRAE
IE
rw rw rw rw
24 23 22
WUTOCLR[15:0]
rw rw rw
8 7 6
WUT[15:0]
rw rw rw
24 23 22
ITSE COE OSEL[1:0]
rw rw rw
8 7 6
SSR
FMT
UIE SHAD
rw rw rw
RM0461 Rev 5
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
RTC register
21 20 19 18
POL COSEL BKP
rw rw rw rw
5 4 3 2
BYP REFCK TS
ON EDGE
rw rw rw rw
RM0461
17 16
rw rw
1 0
rw rw
17 16
SUB1H ADD1H
w w
1 0
WUCKSEL[2:0]
rw rw
