Reset and clock control (RCC)
6.4.23
RCC AHB2 peripheral clock enable in Sleep mode register
(RCC_AHB2SMENR)
Address offset: 0x06C
Reset value: 0x0000 0087
Access: no wait state, word, half-word and byte access
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:8 Reserved, must be kept at reset value.
Bit 7 GPIOHSMEN: IO port H clock enable during Sleep mode.
This bit is set and cleared by software.
0: IO port H clock disabled by the clock gating during Sleep and Stop modes
1: IO port H clock enabled by the clock gating during Sleep mode, disabled during Stop
mode.
Bits 6:3 Reserved, must be kept at reset value.
Bit 2 GPIOCSMEN: IO port C clock enable during Sleep mode.
This bit is set and cleared by software.
0: IO port C clock disabled by the clock gating during Sleep and Stop modes
1: IO port C clock enabled by the clock gating during Sleep mode, disabled during Stop mode
Bit 1 GPIOBSMEN: IO port B clock enable during Sleep mode.
This bit is set and cleared by software.
0: IO port B clock disabled by the clock gating during Sleep and Stop modes
1: IO port B clock enabled by the clock gating during Sleep mode, disabled during Stop mode
Bit 0 GPIOASMEN: IO port A clock enable during Sleep mode.
This bit is set and cleared by software.
0: IO port A clock disabled by the clock gating during Sleep and Stop modes
1: IO port A clock enabled by the clock gating during Sleep mode, disabled during Stop
mode.
278/1306
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
8
7
6
GPIOH
Res.
Res.
SMEN
rw
RM0461 Rev 5
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
GPIOC
Res.
Res.
Res.
SMEN
rw
RM0461
17
16
Res.
Res.
1
0
GPIOB
GPIOA
SMEN
SMEN
rw
rw
