Check Flame Sensor
Check the surface sensor with a digital multimeter. If the
resistance of flame sensor is out of specified values, the
flame sensor is defective.
1. Jacket
2. Combustion chamber
3. Combustion chamber housing
4. Insulation washer
5. Seal - combustion chamber / combustion air fan
6. Seal - combustion chamber / heat exchanger
Specified value
Temperature [°C] -50
0
Resistance [W] 803 1000
Combustion Air Fan
1) Combustion chamber
2) O-ring
3) Rubber seal
4) Combustion air fan
5) Screw
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
10 20 30 80
50
1022 1062 1097 1194 1309
Temperature [°C]
100 150
90 130 200
1347 1385 1498 1573 1758
Combustion
air fan
73
6910
250 300
350 400
1941 2120 2297 2470
