7. Operations when removing and installing the battery
Installed
Removed
Normal Armed
Armed Ready
Armed
Warning
Warning Completion
RELOCK Ready
If the system is in armed mode while installing a battery, the horn sounds and the emergency warning lamp blinks
(Same operations with warning in armed mode).
RELOCK operation
It the door is not opened or the ignition key is not inserted into the key cylinder within 30 seconds after unlocking the
door with remote control key, the system outputs "LOCK" signal and activates the armed mode.
PANIC Warning
1. The PANIC warning output is "ON" (theft deterrent horn) for 27 seconds when receiving the PANIC signal from the
remote control key (pressing PANIC button.
2. The PANIC warning output is "OFF" when receiving any signal from the remote control key during PANIC warning.
3. Followings are theft deterrent warnings:
1) The theft deterrent warning is canceled when receiving PANIC signal from the remote control key during theft
deterrent.
2) The theft deterrent warning output is "ON" when the theft deterrent conditions are established during PANIC
warning (PANIC output is "OFF").
3) The PANIC warning output is "ON" when receiving the PANIC signal from the remote control key in Armed
Ready / Armed / Warning Completion / Relock Ready mode (maintaining the theft deterrent mode).
4. This function operates only in armed mode.
PANIC
TX SIGNAL
(REMOTE
CONTROL NO SIGNAL
KEY SIGNAL)
WARNING
THEFT
DETERRENT
MODE OTHERS
ON
HORN
OFF
SWITCHES / ELECTRIC DEVICES
KYRON SM - 2005.09
Normal
T1
T2
T3
T1: 27 sec T2: 0.5 sec
Armed Warning
T1
T3: 1.0 sec
