Auto Light Control
1. The tail lamps and headlamps can be controlled with the communication with the rain sensor only when the auto
light switch is in the "AUTO" position with the ignition switch "ON".
IGN KEY IGN2
AUTO
LIGHT SW
Headlight
RAIN SENSOR
DATA
Taillamp
TAILLAMP
RELAY
HEADLAMP
RELAY
2. Rain detected headlamp: If it rains heavy which requires the highest INT speed, the headlamps are turned on
automatically.
3. Night detected wiping: When the auto light control turns on the headlamps and the rain sensor detects the rain,
the wiper sensitivity is automatically increased by one level. (i.e. the AUTO wiper switch is at the 3rd level, but
the wiper operates at the 4th level.)
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
ON
OFF
AUTO
OFF
ON
OFF
ON
OFF
Emitter lense
Auto light sensor
Auto light sensor
