SSANGYONG Kyron Repair Manual page 628

44
8710
Receiver
1. Operating requirements
IGN Key = OUT (removed)
2. Code registration requirement
Codes can be registered only through SCAN-100.
3. Transmitter Code Registration
1) Up to two transmitter codes can be registered.
2) The received code cannot be output during the registration.
3) Both single REKES and dual REKES must be encoded through the SCAN-100.
Remote Door Lock
1. All doors are locked when briefly pressing the door LOCK switch on remote control key (less than 0.5 seconds).
2. The system outputs LOCK signal immediately after receiving the door lock message from the remote control
key. The system activates the theft deterrent mode when all doors are locked while they are fully closed (the
hazard warning lamps blink twice.).
REMOTE
CONTROL KEY
PRESS THE DOOR
LOCK BUTTON
OFF
DOOR LOCK
OUTPUT
ON
UNLOCK
DOOR LOCK
SWITCH
LOCK
ON
SENSING
OFF
ON
HAZARD LAMP
OFF
ON
HORN
OFF
RKSTICS (REKES + STICS) / STICS
KYRON SM - 2005.09
Door Lock
0.5 ± 0.1 seconds
Chattering time
0.5 ± 0.1 0.5 ± 0.1
seconds seconds
50 ms
Door Close, Hood Close,
Door Lock, T/Gate Close
0.5 ± 0.1
seconds
