Rear Seat Belt
Preceding Work: Removal of second row seat and third row seat
3. Remove the rear quarter panel and un-
screw the guide pin screw and mount-
ing bolts to remove the seat belt.
Tightening
torque:
35 ~ 55 Nm
O-ring
bracket
D-ring
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
1. Open the bolt cap and unscrew the up-
Anchor bolt
Seat belt
per mounting bolt.
Tightening
torque:
35 ~ 55 Nm
2. Unscrew the lower anchor bolt of the
rear seat belt.
Tightening
torque:
35 ~ 55 Nm
Tightening
torque:
35 ~ 55 Nm
D-ring
SEAT & SEAT BELT
23
7410
KYRON SM - 2005.09
