Step 3
1) Unscrew the mounting bolts from the driver
side instrument panel frame.
2) Unscrew the mounting bolts from the driver
side steering column bracket.
3) Disconnect the main wiring connector (A)
and air bag connector (B).
A
BODY INTERIOR
KYRON SM - 2005.09
B
5) Disconnect the A/C main (A) cable and the
sensor cluster (B) connector and the frame
mounting bolt (center side).
4) Disconnect the center wiring connector and
unscrew the mounting bolt.
