Page 3 When it comes to service, remember that your SSANGYONG dealer knows your vehicle best and is interested in your complete satisfaction.
Page 4: Important Notice
NOTE NOTE indicates information to assist maintenance and instructions. We would like to point out that non Ssangyong Genuine parts and accessories have not been examined and approved by Ssangyong, and in spite of continuous market product monitoring, we cannot certify the suitability nor the safety of such products whether they are installed or intended for fitment in our vehicles.
Page 5 TABLE OF CONTENTS 0. General ............ Section 0 1. Safety Precautions ......... Section 1 2. Ignition Key, Remote Control Key ..Section 2 3. Opening and Closing ......Section 3 4. Interior Switches ........Section 4 5. Instrument Cluster ........Section 5 6.
Page 6 Page 6 2006-05-17, ¿ÀÈÄ 12:56...
Page 7 General TABLE OF CONTENTS Recommended Fluids and Lubricants ..0-2 Dimensions ........... 0-3 Specifications ..........0-4 Vehicle Identification ........0-8 Page 1 2006-05-17, ¿ÀÈÄ 12:56...
Page 8: Table Of Contents
As required Ssangyong genuine oil (DOT4) Power Steering Fluid Ssangyong genuine oil (ATF DEXRON II or III) WARNING • Use only Ssangyong recommended fluids and lubricants. • Do not mix any different types or brands of oils or fluids. This may •...
Page 9: Àèä
DIMENSIONS Unit: mm Top View Front View Side View Rear View * ( ) : Optional Page 3 2006-05-17, ¿ÀÈÄ 12:56...
Page 10 SPECIFICATIONS (I) * ( ) Optional Descriptions D20DT D27DT G32D ← ← General Overall length (mm) 4,660 ← ← Overall width (mm) 1,880 ← ← Overall height (mm) 1,740 (1,755: with roof rack) ← ← Gross vehicle 2,530 weight (kg) ←...
Page 11 SPECIFICATIONS (II) * ( ) Optional Descriptions D20DT D27DT G32D Engine Turbocharger and ← Turbocharger, air-cooled – cooling type Manual Operating type Semi- Remote control, ← – Transmission floor change type ← Gear ratio 4.315 – ← 2.475 – ← 1.536 –...
Page 12 SPECIFICATIONS (III) * ( ) Optional Descriptions D20DT D27DT G32D ← Clutch (M/T) Operating type Hydraulic type – ← Disc type Dry single diaphragm type – ← ← Power Type Rack and pinion Steering ← ← Steering Inner 35.88° angle ←...
Page 13 SPECIFICATIONS (IV) * ( ) Optional Descriptions D20DT D27DT G32D ← ← Air Conditioner Refrigerant (capacity) R-134a (650 ± 30g) ← ← Electrical Battery type / Capacity (V-AH) MF / 12 - 90 ← Starter capacity (V-kW) 12 - 2.2 12 - 1.8 ←...
Page 14: Vehicle Identification
VEHICLE IDENTIFICATION 1. Engine Number 2. Chassis Number Gasoline Engine: The engine num- The chassis number is stamped on ber is stamped on the lower area of the frame behind the front right tire. cylinder block in exhaust manifold side. 3.
Page 15: Safety Precautions 1
Safety Precautions TABLE OF CONTENTS Checks before Starting a Journey ....1-2 Starting the Engine and Driving Off the Vehicle ............1-4 Safety Precautions ........1-6 Direct Injection Type Diesel Engine ..1-11 Page 1 2006-05-17, ¿ÀÈÄ 12:57...
Page 16: Checks Before Starting A Journey
CHECKS BEFORE STARTING A JOURNEY CHECKS BEFORE STARTING A JOURNEY CHECK THE VEHICLE OUTSIDE CHECK THE VEHICLE INSIDE 1. Check the tire inflation and wear. 1. Make sure that all doors including the tailgate are prop- erly closed. 2. Check the engine oil and other fluid/oil levels in the engine compartment.
Page 17: Fuel Recommendation
Gasoline Engine Fuel with too low an octane number can cause pre-ignition Operation in Foreign Countries (detonation). Ssangyong can not be held liable for resultant If you are going to drive your KYRON in another country, be damage. sure to: •...
Page 18: Starting The Engine And Driving Off The Vehicle
STARTING THE ENGINE AND DRIVING OFF THE VEHICLE Automatic Transmission Manual Transmission 1. Apply the parking brake. 3. • Automatic transmission equipped vehicle 2. Make sure that there are no persons or obstacles in the “P” Move the selector lever to the position and depress dangerous area around the vehicle.
Page 19 4. • Diesel engine equipped vehicle: 6. Warm up the engine in idling speed. Do not warm up the engine excessively. Insert the ignition key into the key cylinder and turn it to 7. Make sure that there are no persons or obstacles in the “ON”...
Page 20: Safety Precautions
1. Never use any duplicated key not provided by 1. Never impact the air bag installations by hands or tools. Ssangyong. It may cause a fire due to an overload in 2. The air bag system serves as a supplement to the the electric circuit.
Page 21 Always use only Ssangyong genuine parts for replacement. inoperative. Ssangyong is not liable for any damage caused by the 3. Make sure that all passengers have their body parts use of non-Ssangyong genuine parts and accessories.
Page 22 SAFETY PRECAUTIONS (III) Child Restraint When transporting infants or small children, an appropri- WARNING ate child restraint system should always be used. The child • Do not hold a child while riding in a vehicle. restraint system should be appropriate for your child’s •...
Page 23 SAFETY PRECAUTIONS (IV) Starting the Engine Warming Up the Engine 1. Do not drive without warming up the engine. Driving immedi- “ON” 1. Turn the ignition key to the position and ately after starting the engine may decrease the engine’s life wait until the glow indicator goes out.
Page 24 SAFETY PRECAUTIONS (V) Cautions While Driving Engine Brake 1. Do not turn off the engine while the vehicle is in motion. When driving down a long slope, use the engine brake The power steering function and the brake assist func- effect by downshifting the transmission in steps accord- tion will be deactivated.
Page 25: Direct Injection Type Diesel Engine
When this happens, have the sys- gas (CO, HC, NOx..). Because the Direct Injection Diesel tem checked at a Ssangyong Dealer or Ssangyong Au- Engine is operated by high pressure (1,600 bars), any thorized Service Center.
Page 26 • When engine check warning light comes on, immediately stop driving and have the engine - If this happens, pump fuel until the system checked at a Ssangyong Dealer or Ssangyong Authorized Service Center. priming pump is fully filled. Then, •...
Page 27: Ignition Key, Remote Control Key 2
Ignition Key, Remote Control Key TABLE OF CONTENTS Remote Control Key* and Ignition Key ..2-2 Remote Control Key Functions ....2-4 Key Functions ..........2-6 Immobilizer System* ........2-8 Opening and Closing the Doors with Ignition Key ........2-10 Theft Deterrent System ......
Page 28: Remote Control Key* And Ignition Key
REMOTE CONTROL KEY * AND IGNITION KEY DOOR LOCK/UNLOCK BUTTON 1. Lock (Briefly Press) If you press this button briefly, all doors and the tailgate are locked and the theft deterrent mode is activated. 2. Unlock (Press and Hold) If you press and hold this button for a certain period of time, all doors and the tailgate are unlocked and the theft deter- rent mode is deactivated.
Page 29 FUNCTIONS OF IMMOBILIZER SIMULTANEOUS OPERATIONS OF ROOM LAMPS Immobilizer Function The immobilizer is designed to prevent the possibility of ve- The front and center room lamps come on for 30 seconds hicle theft by allowing only authorized keys to start the engine. when the unlock button on the remote control is pressed and The same code is encrypted in the transponder inside of the hold.
Page 30: Panic Button
REMOTE CONTROL KEY FUNCTIONS PANIC BUTTON DOOR LOCK/UNLOCK BUTTON 1. Lock (Briefly Press) 1. Panic Function • If you press this button, all doors are locked and the • If you are in your vehicle and feel threatened while the theft deterrent mode is activated.
Page 31: Battery Replacement
BATTERY REPLACEMENT When the operational distance noticeably decreases or the Battery Replacement remote control does not work occasionally, replace the bat- tery with a new one. 1. Unscrew two screws from the rear cover. Battery Specifications Model CR 2032 Amount CAUTION •...
Page 32: Key Functions
KEY FUNCTIONS ACC Position • Allows operation of some electrical accessories with ON Position the engine off. • The engine runs and all electri- • Unlock the steering wheel. cal accessories can be used. • The ignition key cannot be removed. •...
Page 33: Cautions When Starting The Engine
• Never use any duplicated key not provided from “LOCK” start, turn the key back to the position and Ssangyong. wait for 10 seconds. Then try again, before any attempt “ON” The duplicated key might not turn back to the to start the engine.
Page 34: Immobilizer System
If this indicator blinks, it may indicate that there is something wrong in the immobilizer system. Have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. NOTE The time needed for communication between the immobilizer key and ECU can vary.
Page 35 • When you modify your vehicle and install a remote engine starter, • The immobilizer system should be inspected, replaced, serviced, you may have some problems starting the engine or some fatal or coded by only qualified service personnel in a Ssangyong Dealer accidents. or Ssangyong Authorized Service Center.
Page 36: Opening And Closing The Doors With Ignition Key
OPENING AND CLOSING THE DOORS WITH IGNITION KEY Locking the door and the tailgate Unlocking the door and the tailgate To Lock the Door: Turn the key to the lock position (toward front of the vehicle) from driver’s door or passenger’s door. All doors and the tailgate will be locked.
Page 37: Theft Deterrent System
THEFT DETERRENT SYSTEM Arming the Theft Deterrent System The theft deterrent system will be armed under the following conditions: • When all doors are locked with the remote control key, the anti-theft mode will be activated. If “UNLOCK” button on the remote control key is pressed and no door is opened within approximately 30 seconds, all doors are automatically locked again and the anti-theft mode will be activated.
Page 38 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 12 2006-05-17, ¿ÀÈÄ 12:57...
Page 39 Opening and Closing TABLE OF CONTENTS Opening and Closing Devices ....3-2 Doors ............3-3 Windows ............3-5 Sunroof* ............3-7 Tailgate ............3-9 Engine Hood ..........3-10 Fuel Filler Door ........... 3-11 Page 1 2006-05-17, ¿ÀÈÄ 12:57...
Page 40: Opening And Closing Devices
OPENING AND CLOSING DEVICES Child Safety Door Lock Tailgate Opening Lever Fuel Filler Door Sunroof Controller Unlock Lock Tailgate Engine Hood Safety Child Safety Door Lock Latch Lever Unlock Lock Rear Door Driver’s Door Win- Fuel Filler Door Release Lever, Door Opening Lever dows Switch Engine Hood Opening Lever...
Page 41: Doors
DOORS DOOR LOCK/UNLOCK KNOB NOTE • The passenger’s door lock/unlock knob All doors will be locked/unlocked when and lever have the same functions with moving the knob to the respective lock/ those of the driver’s door. unlock direction (only available at driver’s Unlock •...
Page 42 CENTRAL DOOR LOCK/UNLOCK SWITCH When the door lock/unlock switch is Driver’s side Passenger’s side pressed while all doors including the tail- gate are locked, all doors will be unlocked. When the switch is pressed again, all doors will be locked. This switch is not available when any of doors are not fully closed and the vehicle is in theft deterrent mode.
Page 43: Windows
WINDOWS Window Lock Switch Driver’s Door Window Switch If the window lock switch is pressed down, • When the front of the switch is lightly passenger’s and rear windows cannot be op- pressed, the window will be lowered erated by their switches. while the switch is pressed.
Page 44: Opening And Closing
Passenger’s and Rear Window Switch Anti-Trap System for Driver’s Window* The anti-trap system enables the driver’s window to auto- Passenger’s seat matically reverse when something is caught in the window as it is closing. When the sensor detects an obstacle, the window will be lowered immediately.
Page 45: Sunroof
SUNROOF* * For your safety, never operate the sunroof when the vehicle is moving. SUNROOF SLIDING OPERATION Open: 2-Step Opening When the sunroof is closed, two thirds of the sunroof au- tomatically opens if the sunroof open/close switch is turned to the “OPEN” direction (Clockwise). When the switch is turned again to the “OPEN”...
Page 46 Battery Discharge or Power Failure while Operating Sunroof If the sunroof is stopped midway due to a discharged battery or power failure, you need to re-calibrate the starting point of the sunroof. In addition, the following cases need the re-calibration. •...
Page 47: Tailgate
TAILGATE Tailgate Opening Lever (Outside) WARNING Exhaust gases are poisonous. Do not run the engine with the tailgate open to avoid exhaust gas in the cabin. Cargo can fall out of an open tailgate To open the tailgate, unlock the while the vehicle is in motion, result- tailgate and pull the tailgate ing in an unexpected accident.
Page 48: Engine Hood
ENGINE HOOD 1. To open the engine hood, pull the release knob located on the lower left side of the steering wheel to unlatch the engine hood. 2. Slightly lift up the engine hood and raise up the safety latch lever with your fingers.
Page 49: Fuel Filler Door
FUEL FILLER DOOR 1. Open the fuel filler door ( ) by pulling the release lever located on the lower left side of the steering wheel. 2. Open the fuel filler cap ( ) by turning it counterclockwise. OPEN 3. After refueling, tighten the fuel filler cap by turning it clockwise CLOSE until you hear clicking sounds.
Page 50 Gasoline Engine CAUTION Fuel with too low octane number can cause pre-ignition Gasoline damages paintwork. (detonation). Ssangyong can not be held liable for resultant If gasoline spills onto paintwork, wash with cold water immediately. damage. CAUTION CAUTION For correct octane rating setting and other use of gasoline (ex.
Page 51 CAUTIONS WHEN OPENING/CLOSING DOORS • Do not allow children to play with any switch, door lever and the gear shift. • Before operating the power windows, doors, sunroof, tailgate and fuel filler door, make sure that noth- ing can be trapped (such as heads, hands, or fingers). •...
Page 52 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 14 2006-05-17, ¿ÀÈÄ 12:57...
Page 53: Interior Switches 4
Interior Switches TABLE OF CONTENTS Interior Switches ......... 4-2 Heated Glass Switch ......... 4-22 Light Switch ..........4-4 Audio Remote Control Switches On Steering Wheel ......... 4-23 Wiper and Washer Switch ......4-8 4-Wheel Drive Switch* ......4-24 Rain Sensing Wiper* ......... 4-10 Switches in Overhead Console ....
Page 54: Interior Switches
INTERIOR SWITCHES Seat position memory switch Sunroof switch Wiper and washer switch Audio remote control switch Light switch Door lock/ unlock switch 4-wheel drive switch Auto cruise* Driver seat heating switch Passenger seat heating switch Window control switches Winter mode switch Door lock/unlock switch Headlight leveling switch INTERIOR SWITCHES...
Page 55 Outside rearview mirror folding switch Outside rearview mirror control switch Rear fog light switch* Outside rearview mirror selection switch switch* HDC switch* Tailgate and outside rearview mirror heated glass switch Hazard warning flasher switch Windshield heated glass switch TRIP/RESET switch INTERIOR SWITCHES Page 3 2006-05-17, ¿ÀÈÄ...
Page 56: Light Switch
LIGHT SWITCH Automatic Light & Rain Light Switch Sensor* You can turn the lights on and off(headlamps, tail lamps, po- This senses the ambient illu- sition lamps, license plate mination intensity to determine lamp, turn signal lamps, fog the timing for turning the lights) with this switch.
Page 57 • Any aftermarket tanning film or spray may cause the lighting sys- tem to malfunction. • Ssangyong recommends you to use this device restrictively around Automatic Light & Rain Sensor* only a sunrise or sunset.
Page 58: Interior Switches
Battery Saver (Automatically turns off the lights) HEADLIGHT LEVELING To avoid discharging the battery, if the tail lamps are on af- SWITCH* ter the ignition key is removed, a buzzer will sound to alert the driver when the driver’s door is opened. The tail lamps will automatically turn off when the door is closed.
Page 59: Light Switch
Headlamp High Beam To turn on the headlamp high beam, Right Turn Signal Switch push the lever towards the instrument cluster with the headlamp low beam NOTE on. The headlamp high beam indica- While the turn signal lamp is turned on, the turn signal tor ( ) in the instrument cluster indicator in the instrument cluster blinks.
Page 60: Wiper And Washer Switch
WIPER AND WASHER SWITCH FRONT WIPER SWITCH MIST The windshield wipers can be operated only when you hold the switch to the “MIST” position. The lever will return to the “OFF” position when released. Stop the operation. AUTO Operates automatically according to the vehicle speed or amount of rain.
Page 61 REAR WIPER SWITCH FRONT AUTO WASHER SWITCH When the front wiper switch is off and this switch is pressed, washer fluid will be sprayed and the wiper will automatically operate 4 times. Then, the When the switch is fully turned, washer fluid will be sprayed again and the wiper will auto- fluid will be sprayed onto the rear win- matically operate 3 times.
Page 62: Rain Sensing Wiper
RAIN SENSING WIPER* “AUTO” When the wiper switch is in the position, this sensor detects the amount of rain, turns on the wiper, and controls the intermittent wiper intervals. Rain and Auto Light Sensor Wiper AUTO Position AUTO It controls the wiping speed by de- tecting the amount of rain drops.
Page 63: Cruise Control Switch* (For Auto T/M)
CRUISE CONTROL SWITCH* (FOR AUTO T/M) CRUISE CONTROL Setting a Desired Speed The cruise control is an automatic speed control system that main- tains a desired driving speed without using the accelerator pedal. The vehicle speed must be greater than 36 km/h to engage the cruise 1.
Page 64 Accelerating with the Cruise Control System Decelerating with the Cruise Control System • While the cruise control system is running • While the cruise control system is running 1. Push up the ACCEL switch of the cruise control lever and 1.
Page 65 Recovery of Set Speed Normal Cancellation of the Cruise Control The cruise control system will be canceled when one or more items of the following conditions are applied; 1. When the brake pedal is depressed. 2. When the cruising speed is downed less than 34 km/h. 3.
Page 66 After you do that, you can use the cruise control system again. But if the cruise control system isn’t recovered, you should con- tact a Ssangyong Dealer for diagnosis of the cruise control system. CAUTION Abnormal changes of the selector lever can damage the engine.
Page 67: Outside Rearview Mirror Control Switch
OUTSIDE REARVIEW MIRROR CONTROL SWITCH Outside Rearview Mirror Folding Outside Rearview Mirror Switch Control To fold the outside rearview mirrors, press the 1. Select the driver side mirror switch. To unfold the mirrors, press again. (L) or the passenger side mir- Mirror Selection Switch ror (R) with the mirror selec- tion switch.
Page 68: Esp Off (Electronic Stability Program) Switch And Esp System
(ELECTRONIC STABILITY PROGRAM) SWITCH AND ESP SYSTEM* ESP Warning Lamp Blinking: When ESP is activated. On: When ESP is deactivated (by pressing the ESP switch). When ESP system is defective. When ESP is activated, the indicator light is blinking and a warning buzzer sounds.
Page 69 Make sure to check the vehicle at the nearest Ssangyong Dealer or Ssangyong Authorized Service Center. stably moving in a certain situation, such as during a sharp corner. The ESP applies brakes on a certain wheel(s) or con- •...
Page 70: Center Switch Panel
CENTER SWITCH PANEL Tailgate and Outside Rearview Mirror Heated Glass Switch Press this switch to turn on the tailgate and out- side rearview mirror heated glasses. The heated glass indicator in the switch comes on. HDC (Hill Descent Control) Switch* The green HDC indicator in the instrument cluster comes on when pressing this switch.
Page 71 TRIP AND RESET SWITCH TRIP/RESET Switch TRIP/RESET switch is used for dif- ferent displays: TRIP A, TRIP B and ODO (the total driving distance) Total driving distance Unit: 0~999999 km 1. Changing the Driving Distance Display Mode Trip A Unit: 0.0~999.9 km •...
Page 72: Hdc (Hill Descent Control) Switch
HDC (HILL DESCENT CONTROL) SWITCH* HDC stands for Hill Descent Control. When traveling down steep grades, this function HDC? allows you to travel at a low speed without any depression of the brake pedal. This conve- nient function is for only driving down steep grades. Therefore do not use this function for anything other than driving down steep hills.
Page 73 HDC Operational Conditions Operation of HDC 1. The HDC switch should be on (The green indicator on When all operational conditions are met, HDC is applied the instrument cluster comes on). and the green HDC indicator blinks. HDC automatically de- creases the vehicle speed to 7 km/h in the 2 wheel (2H) or 2.
Page 74: Heated Glass Switch
HEATED GLASS SWITCH Tailgate and outside rearview mirror heated glass switch • Press this switch to turn on the tailgate and out- side rearview mirror heated glasses. It will oper- ate for about 12 minutes. • Press the switch again to stop the operation. •...
Page 75: Audio Remote Control Switches On Steering Wheel
AUDIO REMOTE CONTROL SWITCHES ON STEERING WHEEL * The audio system equipped in the vehicle can be controlled by the remote control switches on the steering wheel. POWER MUTE Audio power on/off when Stops audio output from the the button is pressed. audio system.
Page 76: 4-Wheel Drive Switch
4-WHEEL DRIVE SWITCH* 4-WHEEL DRIVE SWITCH Only for part time TC, not available for 2-wheel drive vehicle and all wheel drive vehicle. Select a proper driving mode according to the road conditions. NOTICE • Do not drive your vehicle over 80 km/h in 4H mode.
Page 77 • There could be mechanical noises and shocks during mode changes. • If the “4WD CHECK” warning light stays on, have the 4WD system However, these are normal conditions due to the mode changing checked by the nearest Ssangyong Dealer or Ssangyong Authorized operations. Service Center.
Page 78: Switches In Overhead Console
SWITCHES IN OVERHEAD CONSOLE Room Lamp Main Switch When this switch is pressed, the front and center room lamps are turned on. When Spot Lamp Switch pressed again, the lamps go out. (Passenger’s) If switches of the spots and center room The front room lamp (passenger’s) lamps are turned on, the lamps do not go turns on when pressing in this switch.
Page 79 Instrument Cluster TABLE OF CONTENTS Instrument Cluster ........5-2 4WD Indicators (Part time T/C only) ..5-14 Tachometer, Speedometer ......5-3 Engine Overheat Warning Light, Front Fog Light Indicator ......5-15 Coolant Temperature Gauge / Fuel Gauge . 5-4 High Beam Indicator, Door Ajar Warning Display ............
Page 80: Instrument Cluster
INSTRUMENT CLUSTER 1. Tachometer 13. Low fuel level warning light 25. Auto shift indicator (for automatic transmission) 2. Speedometer 14. Winter mode indicator 26. ODOmeter/ Trip odometer 3. Left turn signal indicator 15. ESP warning light 27. ABS warning light 4.
Page 81 TACHOMETER SPEEDOMETER Diesel Gasoline RED ZONE (GCC ONLY) The tachometer indicates engine speed in revolutions per The speedometer indicates the vehicle speed in kilometers minute. Multiply 1,000 to the current number, then it will be per hour (km/h) or mile per hour (km/h). the current number of engine revolutions.
Page 82: Coolant Temperature Gauge / Fuel Gauge
COOLANT TEMPERATURE GAUGE / FUEL GAUGE Coolant Temperature Gauge (A) The temperature gauge indicates the temperature of the en- gine coolant. Fuel Gauge (B) This gauge indicates the level of fuel remaining in the fuel “E” tank. Fill up the fuel tank before the needle reaches CAUTION The engine can overheat.
Page 83: Display
DISPLAY Odometer and Trip Odometer Display Each time the TRIP/RESET switch on the center panel is pressed lightly, the indica- tors are changed. To reset the trip meter, press and hold the switch. Total driving distance Unit: 0~999999 km Auto Shift Indicator (for automatic transmission) Trip A Unit: 0.0~999.9 km This indicator shows the automatic transmission selector lever position as...
Page 84: Battery Charge Warning Light, Air Bag
If it does not come on, or if it does not go off, or if it flashes or Have the charging system checked by a Ssangyong Dealer illuminates continuously while driving, it means that there is or Ssangyong Authorized Service Center.
Page 85: Esp Warning Light
ESP WARNING LIGHT HDC INDICATOR If you press the ESP switch, the ESP function stops and When the HDC switch is pressed once, HDC is ready for the indicator lamp in the instrument cluster comes on. If the use. The green HDC indicator in the instrument cluster ESP function operates, the indicator lamp flickers.
Page 86: Seat Belt Reminder
CAUTION If this indicator blinks, it may indicate that there is something wrong in the immobilizer system. Have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. INSTRUMENT CLUSTER Page 8...
Page 87: Ssps Warning Light
This warning light comes on when the SSPS system is defective. When this warning light comes on, the steering effort becomes heavy. CAUTION If this light comes on, have the SSPS system checked by Ssangyong Dealer or Ssangyong Authorized Service Operation. INSTRUMENT CLUSTER Page 9 2006-05-17, ¿ÀÈÄ...
Page 88: Water Separator Warning Light
Never tions still exist after draining the water, have the system use low quality fuel. checked by a Ssangyong Dealer or Ssangyong Autho- • Before starting the engine, pump fuel until the priming rized Service Center.
Page 89 DIESEL ENGINE HOW TO DRAIN THE WATER FROM THE FUEL FILTER (Without Additional Water Separator) 1. Locate the fuel filter in the engine compartment and place 4. Wait until a certain amount of fuel gets out from the port, a water container under it. then turn the drain plug to the closing direction to tighten it.
Page 90: How To Drain The Water From The Fuel Filter (With Additional Water Separator)
HOW TO DRAIN THE WATER FROM THE FUEL FILTER (With Additional Water Separator) Fuel filter CAUTION Drain the water from the fuel filter & water separator immediately after the warning light comes on. If you cannot do that by yourself, visit the nearest Ssangyong Dealer or Ssangyong Authorized Service Center. WARNING Water...
Page 91 1. Locate the fuel filter ( ) & water separator ( ) in the en- gine compartment. 2. Place the water container under the fuel filter & water separator. 3. Disconnect the connector under the drain plug ( ) of the water separator.
Page 92: 4Wd Indicators (Part Time T/C Only)
If the “4WD tem checked. CHECK” warning light stays on, have the • Do not drive your vehicle over 80 km/h in 4H mode. 4WD system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. 5-14 INSTRUMENT...
Page 93: Engine Overheat Warning Light
ENGINE OVERHEAT WARNING LIGHT FRONT FOG LIGHT INDICATOR When the engine coolant temperate is abnormally hot, the When the tail or head lights are on, the fog lights come on engine overheat warning light blinks and a warning buzzer if the fog light switch is turned to the “ON” position. Then, sounds.
Page 94 HIGH BEAM INDICATOR DOOR AJAR WARNING LIGHT This indicator illuminates when the high beam headlamp is This light comes on when a door or the tailgate is either switched on. opened or not closed completely. WARNING WARNING Driving with high beam headlamp disturbs the approaching vehicle’s Driving with the door open can cause injury to people inside and visibility.
Page 95 WARNING Driving the vehicle with the brake fluid warning light on is dangerous. If the parking brake light stays on, you must immediately have your vehicle checked and serviced by Ssangyong Dealer or Ssangyong Authorized Service Center. 5-17 INSTRUMENT...
Page 96 CAUTION When the glow indicator comes on while driving or the engine can- not be started properly, have the glow plug system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. 5-18 INSTRUMENT CLUSTER Page 18...
Page 97: Abs Warning Light
• If this light doesn’t come on when the ignition is switched to “ON” or if this light doesn’t go out, contact your nearest Ssangyong Dealer or Ssangyong Authorized Service Center. If this light illuminates while driving, a malfunction of ABS is indicated.
Page 98 Otherwise, the hood may be lifted by a strong wind, block driver’s visibility, and cause an accident. If the EBD warning light stays on, have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. 5-20 INSTRUMENT...
Page 99: Engine Check Warning Light
In this mode, the engine driving force may be decreased or the engine may stall. When this happens, have the system checked at the nearest Ssangyong Dealer or Ssangyong Authorized Service Center. If the light stays on or comes on while driving, some of the engine control components including sensors and devices are defective.
Page 100: Engine Oil Pressure Warning Light
Running the engine with the oil pressure warning light on can cause serious dam- age to the engine. Have the lubricating system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. 5-22 INSTRUMENT...
Page 101: Transmission And Brake System 6
Transmission and Brake System TABLE OF CONTENTS Shift Lever in Manual Transmission ... 6-2 Gear Selector Lever in Automatic Transmission ..........6-3 Driving Tips For Automatic Transmission .. 6-4 Gear Selector Lever Positions ....6-6 Winter (W) / Standard (S) Mode ....6-11 Safety Mode (Automatic Transmission) ..
Page 102: Shift Lever In Manual Transmission
SHIFT LEVER IN MANUAL TRANSMISSION The manual transmission in your vehicle has 5 forward gears and 1 reverse gear. To change gears, fully depress the clutch pedal. Then, move the gearshift lever into a desire gear. After shifting, release the clutch slowly. 5th Gear Position for very high speed driving on a highway...
Page 103: Gear Selector Lever In Automatic Transmission
GEAR SELECTOR LEVER IN AUTOMATIC TRANSMISSION To shift into any other position, Mode Switch depress the brake pedal. (The ignition switch should be in “ON”.) • : Winter mode • : Standard mode The shift lever moves only when the brake Use the standard mode in normal driving pedal is depressed.
Page 104: Driving Tips For Automatic Transmission
DRIVING TIPS FOR AUTOMATIC TRANSMISSION Starting and Driving Off “P” 1. Always start the engine while the selector lever is in CAUTION and the brake pedal is depressed. For your safety, avoid • When starting the engine with the accelerator depressed, your ve- “N”...
Page 105 CAUTION Kickdown Function • Do not use the kickdown operation while driving on slippery or If you need to accelerate rapidly, depress the accelerator sharply curved roads. pedal completely to the floor. Then, a one- or two-lever • If you use the kickdown function too frequently, the durability and gear will automatically be engaged.
Page 106: Gear Selector Lever Positions
GEAR SELECTOR LEVER POSITIONS P: PARK POSITION R: REVERSE POSITION Use this position to park your vehicle, warm up the engine, • Use this position to reverse the vehicle. or stay in a location for an extended length of time. “R”...
Page 107: Shift Lever Lock Release
3. Start the engine, release the parking brake, and place the “-D+” selector lever at WARNING If this happens, have your vehicle repaired by the nearest Ssangyong dealer or Ssangyong Authorized Service Center as soon as possible. TRANSMISSION AND BRAKE SYSTEM Page 7 2006-05-17, ¿ÀÈÄ 12:58...
Page 108 N: NEUTRAL POSITION -D+: DRIVE POSITION At this position, the engine does not transfer power to the • Use this position for normal driving conditions. The transmis- sion is automatically shifted from gear up to gears wheels and the vehicle will not move. However, for safety, according to the level of depression on the accelerator pedal.
Page 109 ADJUSTMENT FOR THE SHIFTABLE GEAR IN “-D+” The shiftable gear is down/up by one step as the lever is moved to the left(-)/right(+) direction. Upshift ← ← ← ← When the lever is pushed to the right, the one-step higher gear can be selected per push.
Page 110 • In this position, you can only use the 1st gear in the transmission. Use this position on long mountainous terrains, steep hills, and rough off-road. This also provides the engine brake effect on steep downhills. • The drive position prevents the transmission from shift- ing into the third or fourth gear.
Page 111: Winter (W) / Standard (S) Mode
WINTER (W) / STANDARD (S) MODE MODE SWITCH Use the standard mode in nor- mal driving conditions and use the winter mode on slippery roads. How to start off the vehicle with 2nd forward/ Standard Mode (S) reverse gear • Use the standard mode in normal driving conditions. 1.
Page 112: Safety Mode (Automatic Transmission)
) still exists, • Instrument cluster displays “D” other than “D ” even have the system checked by a Ssangyong dealer or Ssangyong Authorized Service Center. when the gear selector lever is in “-D+” Position. • If the mechanical or electrical problem still exists, have the sys- •...
Page 113: Parking Aid System
PARKING AID SYSTEM “R” When the gear selector lever is shifted into , the parking aid sys- Distance Alarm interval tem is activated and the sensors in the rear bumper detect the distance over 1.2 m to any obstacle. You can figure out the distance from the obstacle to no alarm your vehicle by the alarming sound.
Page 114 “ON”, it means that there is a malfunction in the system. Weak Sensing Scopes Have the parking aid system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. • When they are partially covered by snow or mud.
Page 115: Brake System
BRAKE SYSTEM Brake warning light warning light warning light indicator warning light switch HDC switch Parking brake Parking brake Brake pedal 6-15 TRANSMISSION AND BRAKE SYSTEM Page 15 2006-05-17, ¿ÀÈÄ 12:58...
Page 116: Brake Warning Light
BRAKE PEDAL (FOOT BRAKE) BRAKE WARNING LIGHT The brake pedal (foot brake) is designed to decrease the vehicle speed and stop the vehicle. Do not excessively apply the brake pedal while going down a long hill. The brake sys- tem will overheat causing the vapor lock or fade phenom- enon thus losing braking force.
Page 117 If the ESP warning light comes on, the ESP related system is defective. When the ESP warning lamp is on, push the ESP switch Make sure to check the vehicle at the nearest Ssangyong Dealer or again to re-activate ESP. The system will be resumed and Ssangyong Authorized Service Center.
Page 118 HDC SWITCH* HDC INDICATOR* When this button is pressed Green light on: HDC is ready for use (by once, HDC is ready for use. pressing the HDC switch). The green HDC indicator in Green light blinking: HDC is being applied. the instrument cluster comes Red light on: the HDC system is over- on.
Page 119: Abs Warning Light
• If this light doesn’t come on when the ignition is switched on or if If the EBD warning light stays on, have the system checked at the this light doesn’t go out, contact your nearest Ssangyong Dealer or Ssangyong Dealer or Ssangyong Authorized Service Center.
Page 120: Parking Brake Operation
Lift up the brake lever a little and press the release button Ssangyong Dealer or Ssangyong Authorized Service Center. at the end of the lever. Then, push down the lever.
Page 121: Seat
Seats TABLE OF CONTENTS Driver’s Seat (Power Seat)* ......7-2 Driver’s Seat (Manual Seat) ......7-4 Passenger’s Seat ......... 7-5 Position Memory Setting* ......7-6 Second Row Seat ........7-8 Seat Heating System* ....... 7-10 Warning and Caution ......... 7-11 Page 1 2006-05-17, ¿ÀÈÄ...
Page 122: Driver's Seat (Power Seat)
DRIVER’S SEAT (POWER SEAT)* Head Restraint Adjustment To raise the head restraint, WARNING pull it up without pressing Do not adjust the driver’s seat when the vehicle is the release button. To lower moving. Control of the vehicle can be lost. the head restraint, press the release button on top of...
Page 123 Seatback Pocket There is a storage pocket for storing small items. Lumbar Support (Driver’s Seat) Seat Heater (If equipped) By operating the seat heater switch, you can heat the seat cushion and seatback. Turn the lever forward to in- crease the amount of lum- bar support.
Page 124: Driver's Seat (Manual Seat)
DRIVER’S SEAT (MANUAL SEAT) Seatback Reclining Adjustment Head Restraint Adjustment To change the seatback angle, Same as that of the power seat lean forward slightly and raise the lever. Then, lean back to the de- Lumbar Support sired angle and release the lever. Same as that of the power seat After adjusting, make sure the le- ver is returned to its original posi-...
Page 125: Passenger's Seat
PASSENGER’S SEAT Power Seat* Manual Seat Seat Heater* Seat Heater* Seat Slide Seat Slide Seatback Reclining Seatback Reclin- Adjustment Adjustment Adjustment ing Adjustment 7 - 5 ½ÃÆ® ¹× ½ÃÆ® ÆíÀÇÀåÄ¡ SEATS Page 5 2006-05-17, ¿ÀÈÄ 12:58...
Page 126: Position Memory Setting
POSITION MEMORY SETTING* The position memory is available for up to three drivers. Each driver can set his/ her own driver’s seat, outside rearview mirrors. The information will individually be stored in the integrated computer. If somebody has moved the seat, the memory positions can be recalled automatically by pressing the position button.
Page 127 CAUTION CAUTION • If you adjust your seat or any outside rearview mirrors in the middle of setting up or recall of the memory, the setup or recall is can- celled and stops operating. • In case of an automatic transmission vehicle, this function will not work if the parking brake is not engaged and the gear selector le- “P”...
Page 128: Second Row Seat
SECOND ROW SEAT Head Restraint Adjustment To raise the head restraint, pull it up without pressing the release button. To lower the head restraint, press the release button ( ) on top of seatback and push the head restraint down. WARNING Removed or improperly adjusted head restraints can result in serious head and neck injuries in case of a...
Page 129: Full Flatting The Seat
FULL FLATTING THE SEAT 2. To make a full flat cargo room, fold the second row 1. Pull up the second row seatback folding levers ( ). seatbacks until they click. Make sure that the seatbacks are locked. 3. To raise up the second row seatbacks, release the levers up ( ) and raise up the seatbacks.
Page 130: Seat Heating System
• If the temperature continues to rise, turn the switch off and have the system and press again to stop the seat checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. heating. During heating, the in- • In the case of the driver’s seat, an excessive usage of the heated seat dicator light on the switch might make you sleepy and could negatively affect your safety.
Page 131: Warning And Caution
WARNING AND CAUTION WARNING AND CAUTION WARNING CAUTION • All necessary driver’s seat adjustments should be made before • Power seats will be operated even when the ignition switch is any driving. turned to the “OFF” position. However, to prevent battery discharge, operate your seats when the engine is running.
Page 132 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 12 2006-05-17, ¿ÀÈÄ 12:58...
Page 133 Seat Belt and Air Bag TABLE OF CONTENTS Seat Belt and Air Bag ......... 8-2 Seat Belt ............8-4 How to Fasten the Three Point Seat Belt .. 8-5 How to Fasten the Seat Belts in Second Row Center Seat ......8-6 Child Restraints and Pregnant Woman ..
Page 134: Seat Belt And Air Bag
SEAT BELT AND AIR BAG To protect you and your passengers in the event of an accident, it is highly recommended that the seat belts should be used by all occupants inside of your vehicle. Front Air Bags Three point Three point seat belt seat belt...
Page 135 • Modifications and improper maintenance for the safety systems could cause serious injury. The safety systems including seat belts should be checked and repaired by only a Ssangyong Dealer or Ssangyong Authorized Service Center.
Page 136: Seat Belt
SEAT BELT SEAT BELT IN FRONT SEATS Seat Belt Height Adjustment • To raise the seat belt, slide the seat belt height adjustor up. • To lower the seat belt, press the button and slide it down. WARNING Fastening the Seat Belt •...
Page 137: How To Fasten The Three Point Seat Belt
HOW TO FASTEN THE THREE POINT SEAT BELT 1. Pull out the latch plate from the 2. Position the shoulder belt across the 4. Pull the latch plate to make sure it is retractor. If the seat belt is locked body and the lap belt as low as pos- securely locked.
Page 138: How To Fasten The Seat Belts In Second Row Center Seat
HOW TO FASTEN THE SEAT BELTS IN SECOND ROW CENTER SEAT LAP BELT (GENERAL) 1. Pull out the latch plate at the right of the seat. WARNING Put the lap belt as low as possible across the hips. Do not put it across waist.
Page 139 REAR THREE POINT SEAT BELT* 1. Pull out the smaller latch plate (B) from up- per retractor (1). 2. Insert it into the black buckle (3) until it clicks. 3. Pull out the bigger latch plate (A) and posi- tion the seat belt across your shoulder, chest and hips.
Page 140: Pregnant Women
CHILD RESTRAINTS AND PREGNANT WOMAN PREGNANT WOMEN CHILD RESTRAINTS We recommend that pregnant women When transporting infants or small children, an appropriate child restraint use the seat belts throughout their system should always be used. The child restraint system should be ap- pregnancy.
Page 141 TYPE A TYPE B Rear-facing child seat Forward-facing child seat Booster seat Rear Rear Front Mass Group Restraint Device Figure center side Mounting Method of Vehicle seat seat seat O ~ up to 10 kg (0 ~ 9 month) Rear facing child seat 3-point belt rear-facing O+ ~ up to 13 kg (0 ~ 2 year) Rear facing child seat...
Page 142 INFANT AND CHILD SAFETY Child Seat How to use Child Anchor Children that are too small to use the seat belts must be 1. Engage the attaching clip of the child seat with one of properly secured in a child restraint system. the child restraint anchorages provided floor.
Page 143 ANCHORAGE LOCATIONS NOTE Use the child restraint anchorage for designed purpose only. • Front seat (with Passenger Air Bag) “It is possible to the forward facing universal category child seat.” • Front seat (without Passenger Air Bag) “It is possible install the forward and rearward facing univesal category child seat.”...
Page 144 Since a safety belt or child restraint system can become very hot If you have any queries regarding the installation of a child if it is left in a closed vehicle, be sure and check the seat cover restraint, consult a Ssangyong Dealer. and buckles before placing a child there. 8-12...
Page 145 2. Attachment bolt 3. Lock washer A 5/16"-UNC-2B-bolt with a thread length of 30 mm is used to attach the anchor fittings to the vehicle anchorage. For fitting advice, please contact your authorized Ssangyong Dealer. 8-13 SEAT BELT AND AIR BAG Page 13 2006-05-17, ¿ÀÈÄ...
Page 146: Warnings For Seat Belt
No replacement is • Do not buck up two or more persons with one seat belt. required after a minor collision if a Ssangyong Dealer or • Do not wear the seat belt over any hard or breakable Ssangyong Authorized Service Center finds that no dam- objects in pockets or on clothes.
Page 147 WARNINGS FOR SEAT BELT • Replace the entire seat belt assembly after a severe im- • Keep the buckle clean. pact even if the damage is not obvious. • Seat belts are designed to bear upon the bony structure • Never modify the seat belt. of the body, and should be worn low across the front of the pelvis or the hips, chest and shoulders, as applicable;...
Page 148: Air Bag
If this lamp does not go out after engine starting or comes on while driving, it means that there is a malfunction in the system. Have the air bag system checked immediately by a Ssangyong Dealer or Ssangyong Authorized Service Center. Side Curtain Air Bag* Passenger’s Air Bag*...
Page 149 SRS AIR BAG Locations of Air Bag Warning Labels The Supplemental Restraint System air bag is designed to supplement the seat belts and provide the driver and front passenger with protection against head, chest, and other injuries in the event of a collision. For maximum protection, seat belts should always be worn by all occupants.
Page 150: Front Air Bags
FRONT AIR BAGS Air Bag Operation The air bag inflates when: • In response to a severe frontal impact, the driver’s and front passenger’s air bags deploy at the same time to supple- ment the seat belts to prevent or reduce any personal injuries. The air bag can inflate when: •...
Page 151: Curtain Air Bag
CURTAIN AIR BAG* Curtain Air Bag Operation The air bag inflates when: • A moderate to severe impact to the middle of the ve- hicle body’s side structure. The air bag can inflate when: • Vehicle rolls onto its side and causes a severe side impact.
Page 152: Warnings For Air Bag
Center. tools. You may get injured by sudden deployment. • Replace the steering wheel with only Ssangyong genu- • The air bag contains explosive materials, so contact a ine parts.
Page 153 • Hold only the outer rim of the steering so that the air bag Ssangyong Dealer or Ssangyong Authorized Service can inflate without any hindrance. Center.
Page 154 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 22 2006-05-17, ¿ÀÈÄ 12:59...
Page 155: Ventilation, Heating, Air Conditioning
Ventilation, Heating, Air Conditioning and Air Purification System TABLE OF CONTENTS Heater / Air Conditioner System ....9-2 Warnings and Cautions ....... 9-4 Supplementary Heating Device ....9-5 Automatic Heater / Air Conditioner* ..9-6 Manual Heater / Air Conditioner ....9-10 Defogging and Defrosting ......
Page 156: Heater / Air Conditioner System
HEATER / AIR CONDITIONER SYSTEM Sun Sensor Heater/AC Control Panel VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM Page 2 2006-05-17, ¿ÀÈÄ 12:59...
Page 157 Front Center Vent Front Side Vent Dial type lever You can adjust the direction of the airflow by moving You can adjust the direction of the airflow by moving the knob horizontally or vertically. the airflow direction control lever on the air outlet. VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM Page 3 2006-05-17, ¿ÀÈÄ...
Page 158: Warnings And Cautions
WARNINGS AND CAUTIONS Refrigerant Specification & Capacity CAUTION Item • If your vehicle has been parked in direct sunlight, open all win- R134a Specification dows to extract heat before turning on the air conditioning (A/C). Capacity 650 ± 30g • Operating the air conditioning (A/C) for a long time while the vehicle is parked may cause the engine to overheat.
Page 159: Supplementary Heating Device
SUPPLEMENTARY HEATING DEVICE • The vehicle equiped with the DI engine has the supplementary heating devices to increase the heating effect before the engine coolant fully warms up. The supplementary heating devices are as follows: (Positive Temperature Coefficient) This supplementary heater is an electrical air heating type and installed on the heater outlet port. This device improves the heating effect by increasing the temperature of flowing air into the passenger room.
Page 160: Automatic Heater / Air Conditioner
AUTOMATIC HEATER / AIR CONDITIONER* If the Auto button is pressed, the temperature of the passenger compartment is automatically maintained according to the set temperature. By operating the relevant switch of the automatic air conditioner, you may also manually control the air condi- tioner operation, air flow direction, fan speed and air source.
Page 161 Temperature Control Switch Fan Speed Control Switch To adjust the temperature, turn the To control the fan speed, turn this switch. When turning switch as required. this switch in the Auto mode, the “AUTO” indicator goes out and the system is changed to the manual mode. CAUTION If the air conditioner switch is turned off, the air conditioner does not work even when the fan switch is operated.
Page 162 Air Conditioner Switch Defroster Switch Use this switch for quick defrosting. When you press this switch, the ( ) indicator comes on and the air conditioner starts to operate, however, the When you press this switch, the airflow direction will be “AUTO”...
Page 163 Air Source Selection Switch AQS indicator Air circulation By pressing the switch, the fresh air intake mode and recirculation mode change alternatively. WARNING • Use of the recirculation mode for a long period of time can cause stuffiness, headache, drowsiness, or fogged window. •...
Page 164: Manual Heater / Air Conditioner
MANUAL HEATER / AIR CONDITIONER You can have a pleasant interior temperature by manually turning on or off the air conditioning or heating system, controlling the fan speed ranging from 1 to 4 and the temperature of air, and adjusting the direction of air flow. Bi-level Defroster switch Temperature...
Page 165 The fan speed can be adjusted in 4 different stages. Cool Fan Control Switch Temperature Control Switch Turn the switch clockwise or counterclockwise to increase Adjust the temperature of flowing air by turning the dial. or decrease the fan speed. Red direction: Hot When the switch is turned to “0”, the fan stops.
Page 166 Air Conditioner ON/OFF Switch To turn on the air conditioner, press this switch when the fan speed switch is in any position except “0” position. Then, the indicator in the switch comes on. To turn off the air conditioner, press the switch again. Air conditioner Air circulation ON indicator...
Page 167 Defroster Switch Use this switch for quick defrosting. When you press this switch, the airflow direction will be changed to the windshield and door glasses, the air condi- tioner operates automatically, outside air comes in, and the indicator on the switch comes on. When the switch is pressed again, the previous mode will be restored.
Page 168: Defogging And Defrosting
DEFOGGING AND DEFROSTING Inside of the Windshield Automatic Air Conditioner 1. Press the defroster switch. 2. Adjust the fan speed with the fan speed control. 3. To quickly remove the fog on the glass, set the fan speed switch at a high speed position. 4.
Page 169: Aqs (Air Quality System)
AQS (AIR QUALITY SYSTEM) AQS SYSTEM? AQS automatically adjusts from the fresh air intake mode to the recirculation mode when polluted air is detected by the AQS sensor. The air source selection returns back to the fresh air intake mode if a certain time passes or the polluted air has disappeared.
Page 170: Replacing Air Conditioner Filter
REPLACING AIR CONDITIONER FILTER Replace the air conditioner filter when • Unpleasant odor is generated at the first operation after a long unused period. • Cooling and blowing capacity have decreased. CAUTION CAUTION • Do not apply excessive force to the holders when removing the •...
Page 171 This protruding section indicates that this is the bottom of the filter. 4. Remove the filter cover. 5. Pull out the first filter. 6. Slightly move the second filter to the left side and pull it out. 7. Istall in the reverse order of removal. 9-17 VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM Page 17...
Page 172 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 18 2006-05-17, ¿ÀÈÄ 12:59...
Page 173 Turbocharger System TABLE OF CONTENTS Cautions in Using the Turbocharger ..10-2 Preventive Maintenance ......10-3 Turbocharger Inspection ......10-4 Page 1 2006-05-17, ¿ÀÈÄ 12:59...
Page 174: Cautions In Using The Turbocharger
CAUTIONS IN USING THE TURBOCHARGER WHAT IS THE TURBOCHARGER? Turbochargers are based on the gas turbine engine technology, but operate under consid- erably greater pressure. The turbocharger con- sists of two turbo elements, a turbine and a compressor, both of which are driven from the main center shaft.
Page 175: Preventive Maintenance
PREVENTIVE MAINTENANCE The vehicle owner should be encouraged to observe the fol- CAUTION lowing precautions to ensure maximum turbocharger ser- • At low ambient temperature, or when ever the vehicle has not vice life. been used for a long period, normal engine oil pressure and flow is affected.
Page 176: Turbocharger Inspection
TURBOCHARGER INSPECTION Good maintenance practices should be observed, particu- WARNING larly regarding air filtration, oil quality and filtration. Operating the turbocharger system without the intake and exhaust These areas are important because of a turbocharger’s oper- manifold mounting can result in severe engine damage. ating speed.
Page 177 Convenience Devices TABLE OF CONTENTS Storage Boxes and Convenience Device ... 11-2 Removable Ashtray / Storage Box (Front) ..............11-11 Tiltable Steering wheel and Horn ..... 11-4 Cigarette Lighter ........11-12 Inside Rearview Mirror ....... 11-5 Power Outlet ..........11-13 Map Pocket ..........
Page 178: Storage Boxes And Convenience Device
STORAGE BOXES AND CONVENIENCE DEVICE Sunglasses box Passenger’s sun visor Driver’s sun visor Inside rearview mirror (ECM*) Digital clock Horn Glove box Cigarette lighter Passenger’s door Power outlet Driver’s door map pocket map pocket Center console 11-2 CONVENIENCE DEVICES Page 2 2006-05-17, ¿ÀÈÄ...
Page 179: Convenience Devices
WARNING • Driving with any storage box open can cause injury in case of an accident or a sudden stop. Keep all the storage boxes closed while driving. • Do not store any flammable items or disposable lighters in the console box or other space. In hot weather, they can explode and cause a fire. •...
Page 180: Tiltable Steering Wheel And Horn
TILTABLE STEERING WHEEL AND HORN Horn Tiltable Steering Wheel Press the horn pad on the steer- ing wheel to sound the horn. CAUTION The sound of the horn can startle pedestrians. Use only when needed. To adjust the steering wheel, push the con- trol lever to right, adjust the wheel up or down to the proper position, release the control lever to lock the wheel in place.
Page 181: Inside Rearview Mirror
The inside rearview mirror can be adjusted up, down or side ways INSIDE REARVIEW MIRROR to obtain the best rear view. ECM* (ANTI-GLARE AUTO ADJUSTMENT MANUAL TYPE INSIDE REARVIEW MIRROR FUNCTION) Illumination sensor The reflection rate of the inside rearview mirror can be automati- Manual Day/Night Adjustment cally adjusted by the light intensity from a vehicle behind you.
Page 182: Map Pocket
MAP POCKET FRONT DOOR REAR DOOR The map pocket is located on each front door. Maps, magazines, newspapers, and other items can be stored. 11-6 CONVENIENCE DEVICES Page 6 2006-05-17, ¿ÀÈÄ 12:59...
Page 183: Center Console
CENTER CONSOLE AND FRONT CUP HOLDER CENTER CONSOLE FRONT CUP HOLDER Push the button and lift the cover lid to open in order to store The holder is located in order to put the cup or ashtray into small items. It can be used as an armrest for both the driver it.
Page 184: Overhead Console
OVERHEAD CONSOLE WITH SUNROOF WITHOUT SUNROOF Press the button to open the console and place the sun- glasses onto the hook. CAUTION • If glasses falls down, it may be damaged. Fix it firmly. • The unclosed console can block your rearview. Also, the console can injure you in an accident or a sudden stop.
Page 185 CARD HOLDER / SUN VISORS AND VANITY MIRROR LAMP CARD HOLDER SUN VISORS AND VANITY MIRROR LAMP* Vanity mirror Sun visor Illumination lamp* Tickets and cards can be stored. Sun Visors Pull the sun visor down or to the left (right), if necessary. Vanity Mirror Swing the sun visor down and open the cover to reveal the mirror.
Page 186: Glove Box / Digital Clock
GLOVE BOX / DIGITAL CLOCK GLOVE BOX DIGITAL CLOCK Setting button Hour adjusting button Minute adjusting button Pull up on the lever to open the glove box. Items can be (HOUR) : Hour Adjusting Button stored. (MINUTE) : Minute Adjusting Button When the tail lights are on and the glove box is open, the (SET) : Setting Button glove box inner lamp comes on.
Page 187 REMOVABLE ASHTRAY / STORAGE BOX (FRONT) REMOVABLE ASHTRAY STORAGE BOX (FRONT) Standard Deluxe If you open the lid at night or in a dark area, the ashtray light There is another front storage box at the bottom of the center will light up inside the ashtray.
Page 188: Cigarette Lighter
• When the cigarette lighter does not automatically pop up after 30 seconds, there is a danger of overheating. If this happens, pull it out and have the problem corrected by Ssangyong Dealer or Ssangyong Authorized Service Center. • Inserting your finger into the cigarette lighter outlet can cause burns or electric shock.
Page 189: Power Outlet
POWER OUTLET FRONT POWER OUTLET REAR POWER OUTLET An auxiliary power outlet for extra electrical devices is WARNING installed. This power outlet supplies power when the ignition • For the extra electrical devices, you must use this power outlet. key is in the “ACC” or “ON” position. If you alter the vehicle's wire lines and leave the wires to hang freely, it could cause an accident like a fire.
Page 190: Rear Armrest / Assist Grip And Coat Hook
REAR ARMREST / ASSIST GRIP AND COAT HOOK REAR ARMREST (CENTER) ASSIST GRIP AND COAT HOOK Coat hook The rear armrest is located in the center of the rear seat. Assist grip is not installed on the driver side. A coat hook is Pull down the armrest to use.
Page 191: Luggage Room Lamp
ROOM LAMPS FRONT ROOM LAMP When this switch is pressed, Main switch the front and center room lamps are turned on. When pressed again, the lamps go out. * When a door is opened, the front and center room lamps are turned on.
Page 192: Rear Storage Box And Seatback Pocket
REAR STORAGE BOX AND SEATBACK POCKET REAR STORAGE BOX SEATBACK POCKET Rear storage box Rear storage box is located behind the center console. There is a storage pocket for storing small items. 11-16 CONVENIENCE DEVICES Page 16 2006-05-17, ¿ÀÈÄ 12:59...
Page 193: Luggage Net And Luggage Hooks
LUGGAGE NET AND LUGGAGE HOOKS LUGGAGE NET LUGGAGE HOOKS* Any possibly moving objects during driving can be stored Your vehicle has luggage hooks on the luggage room floor. securely in the luggage net. WARNING Hook the net up to the luggage compartment. The luggage hooks should be used to secure all loads in the lug- gage room by using the proper straps.
Page 194: Rear Defogger And Antenna
REAR DEFOGGER AND ANTENNA* TV antenna* Heating grids and radio antenna The glass antenna (for FM and AM) is on the upper and lower section of the tailgate window and the heating grids are on the center section of the tailgate window. TV anten- nas (If equipped) are installed on both sides of the glass of the tailgate.
Page 195 LUGGAGE COVER* (EXCEPT FOR 7-SEATER) When Unrolling the Luggage Cover Pull the handle of the luggage cover at the center, and fix it into the grooves at left and right sides of quarter trim inner panels. When Rolling the Luggage Cover Take the luggage cover out of the grooves by pulling the handle and let go the grasp slightly to roll the luggage cover.
Page 196: Audio / Video System
AUDIO / VIDEO SYSTEM Audio switch in the steering wheel AV monitor* (touch panel type) 11-20 CONVENIENCE DEVICES Page 20 2006-05-17, ¿ÀÈÄ 1:00...
Page 197 CAUTIONS WHEN USING AUDIO/VIDEO SYSTEM • An illegal copy of a CD/DVD may cause a malfunction Usable Discs in the audio/video head unit and abnormal replay. Use only original CD/DVDs. Head Unit • Incompatible discs may cause a malfunction in the •...
Page 198 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 22 2006-05-17, ¿ÀÈÄ 1:00...
Page 199 In Case of Emergency TABLE OF CONTENTS Starting the Engine with Jumper Cables . 12-2 Shift Lever Lock Release and Safety Mode Reset ..........12-17 Cautions when a Tire is Flat ..... 12-4 Towing a Disabled Vehicle ...... 12-18 OVM Tools ..........12-5 Emergency Towing ........
Page 200: Starting The Engine With Jumper Cables
STARTING THE ENGINE WITH JUMPER CABLES If the batter is weak or dead, the battery from another vehicle can be used with jumper cables to start the engine. Booster battery The positive (+) cable to the positive (+) terminal. The minus (–) cable to the minus (–) terminal.
Page 201: In Case Of Emergency
WARNING • Connecting the jumper cable to the negative terminal of the discharged battery could result in arcing and possibly a battery explosion. Serious personal injury or vehicle damage can result. • Make sure that the jumper leads are securely connected. Otherwise, an abrupt dis- connection due to vibration during engine starting may cause an electrical short re- sulting in severe damage to electric components.
Page 202: Cautions When A Tire Is Flat
CAUTIONS WHEN A TIRE IS FLAT If one of the tires becomes flat while driving, grab the steer- ing wheel firmly and remove your foot from the accelerator pedal. Gradually slow down and park your vehicle in a safe place. Replace the flat tire with a spare tire. For the process, refer to sections about the spare tire.
Page 203: Ovm Tools
OVM TOOLS Jack and OVM tool box Jack extension storage box Emergency tools such as the jack, the jack connection, and 1. Jack others are stored inside of the 3rd row side jack box and the 2. Jack connection floor jack extension storage. 3.
Page 204: Changing A Flat Tire
CHANGING A FLAT TIRE Jack and OVM tool box Jack extension storage box 1. Stop your vehicle in a safe place and turn on the hazard 4. Pull out the jack, the wheel nut wrench, OVM tool and the flasher and then apply the parking brake. jack connection.
Page 205: Removing The Spare Tire
Ssangyong authorized service center or a tire-specialized shop to replace it with a new regular tire.
Page 206: Changing A Spare Tire
CHANGING A SPARE TIRE 1. Pry off the wheel cap with a flat blade screwdriver. 2. Loosen the wheel nuts one or two turns by turning them counterclockwise with the wheel nut wrench. WARNING WARNING • The parking brake should always be applied when replacing the •...
Page 207 3. Place the jack directly under the jack-up points so that the Front jack up point top of the jack contacts the vehicle at the jack-up point. WARNING Do not attempt to raise the vehicle until the jack is set up at the jack up point.
Page 208 Jack knob 4. Combine the jack, the wheel nut wrench and the jack con- 6. Take the wheel off and place the wheel under the vehicle nection as shown in the figure. Jack up the vehicle by body. This helps to minimize any danger if the jack slip off rotating the combined wrench clockwise until the tire is position.
Page 209 8. Lower the vehicle by rotating the combined wrench Tighten up the wheel nuts in the diagonal sequence as counter-clockwise until the tire touches the ground. Re- shown in the picture. Each nut should be turned a couple move the jack. of times at a time.
Page 210 • The temporary spare tire is only for emergency situations. Never use it for normal driving. After installing the spare tire on a wheel, take your vehicle to a Ssangyong authorized service center or a tire-specialized shop to replace it with a new regular tire.
Page 211: Cautions When Changing The Tire
• Never apply oil or grease to either wheel studs or nuts as it will cause them to overtighten. After changing the tire • Check, repair, and retighten the replaced tire at the nearest Ssangyong Authorized Service Center or a quali- fied tire shop after an emergency change.
Page 212: When The Engine Is Overheating
WHEN THE ENGINE IS OVERHEATING Engine over- heat warning lamp Coolant tem- perature gauge When the engine overheats, steam or spray may come out Symptoms: the engine compartment. Or, the coolant temperature gauge touches “H”. If this happens, the engine overheat warning •...
Page 213 Then, put the cap back on the tank. 8. If the coolant level is normal, have the cooling system checked by a Ssangyong Dealer or Ssangyong Autho- rized Service Center. 12-15...
Page 214: Water Separator Warning Light And Engine Check Warning Light
& the water separator. If the above conditions are still existing after draining the water, have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. 12-16...
Page 215: Shift Lever Lock Release And Safety
2nd reverse gear in the position) Then, with the brake pedal depressed, move the selector still exists, have the system check by a Ssangyong Dealer or Ssangyong Authorized Service Center. “N” lever to 3. Start the engine, release the parking brake, and place the “-D+”...
Page 216: Towing A Disabled Vehicle
TOWING A DISABLED VEHICLE Flat-bed equipment is the best method of moving a disabled If not available to use a car carrier, tow the vehicle as vehicle to avoid any damages. illustrated. The vehicle equipped with the AWD system should be towed Choose an appropriate towing method based upon vehicle by this way.
Page 217: Emergency Towing
EMERGENCY TOWING Location of Towing Hooks Rear towing hook Front towing hook Within 5 m • When towing your vehicle with the towing rope: CAUTION 1. Securely tie up the towing rope to the towing hooks. Se- • If you cannot use a professional towing service, the driver of the cure the rope to both of the towing hooks under the front towed vehicle should stay behind the steering wheel.
Page 218: Trailer Towing
The weight of your loaded trailer (gross trailer weight) should ensure that the correct equipment is fitted to your vehicle. never exceed the specified values. Your Ssangyong Dealer will help supply and install towing The maximum permissible trailer ball weight is 117 kg. equipment to suit your requirement.
Page 219 Maximum Load Limits (unit: kg) Maximum permissible Maximum static vertical load on Engine Type Trailer the coupling device 2,100 with brake 2,300 without brake D20DT 2,100 with brake 2,300 without brake 1,950 with brake D27DT 2,300 without brake with brake 2,300 G32D without brake...
Page 220: Trailer Lights
TRAILER BRAKES WARNING In higher elevations the engine output and gradability may drop so If the trailer brakes are used, you should follow all instruc- that it may not be possible for the permissible trailer loads to be tions provided by the manufacturer. Never modify the brake fully utilized in mountainous territory.
Page 221: Brake Fluid
BRAKE FLUID • Allow adequate stopping distance. Stopping distance is increased when you tow a trailer. Change the brake fluid every 15,000 km (9,000 miles) un- • Avoid holding the brake pedal down too long or too der the following conditions. frequently, which will cause the brakes to overheat and - Towing a trailer frequently.
Page 222: Parking On Hills
PARKING ON HILLS WHEN YOU ARE READY TO LEAVE AFTER PARKING ON A HILL You really should not park your vehicle, with a trailer attached, on a hill. If something goes wrong, your rig could start to 1. Apply your regular brakes and hold the pedal down while move.
Page 223: Accident Or Fire
ACCIDENT OR FIRE If your vehicle catches on fire, don’t panic. Evacuate any occupants and use the extinguisher. ACCIDENT Turn on the emergency hazard warning switch. If possible, WARNING move your vehicle to a safe place to avoid any secondary •...
Page 224: Warning Triangle
2. Have all passengers get out of the vehicle and stay away from the traffic. When your safety is secured, contact your Ssangyong dealer for your emergency service. When you pull over your breaking down vehicle to a safe CAUTION place, set up a warning triangle behind your vehicle.
Page 225: Power Steering Fluid
Service and Maintenance TABLE OF CONTENTS Daily Check List ......... 13-2 Fuse and Relay Box ......... 13-22 Locations in Engine Compartment ..13-3 Tire ............13-27 Engine Oil ..........13-6 Spare Tire and Winter Tire ...... 13-29 Engine Coolant .......... 13-9 Wiper Blade Replacement ......
Page 226: Daily Check List
8. Check the brake’s and clutch pedal’s free play, height and function. 9. Check the seat belts. CAUTION If in doubt about driving and operating conditions, have your vehicle checked at a Ssangyong Dealer or Ssangyong Authorized Service Center. 13-2 SERVICE AND MAINTENANCE Page 2 2006-05-17, ¿ÀÈÄ 1:00...
Page 227: Locations In Engine Compartment
D27DT DIESEL ENGINE LOCATIONS IN ENGINE COMPARTMENT CAUTION Do not work on the engine compartment while the engine, radiator, exhaust manifold, muffler or catalytic converter is hot. Always turn the engine off and allow it to cool before starting the maintenance. Brake and clutch fluid reservoir Coolant surge tank (for manual transmission)
Page 228 D20DT DIESEL ENGINE LOCATIONS IN ENGINE COMPARTMENT Coolant surge tank Relay and fuse box Brake and clutch fluid reservoir (for manual transmission) Engine oil filler cap Air cleaner Battery Engine oil dipstick With Additional Without Additional Water Separator Water Separator Front washer Power steering fluid reservoir...
Page 229 GASOLINE ENGINE LOCATIONS IN ENGINE COMPARTMENT Coolant surge tank Brake and clutch fluid reservoir (for manual transmission) Relay and fuse box Engine oil dipstick Engine oil Air cleaner filler cap Front washer Battery Power steering fluid reservoir fluid reservoir 13-5 SERVICE AND MAINTENANCE Page 5 2006-05-17, ¿ÀÈÄ...
Page 230: Mb Sheet No.
D20DT 7.5L filler cap Engine oil D27DT 8.5L dipstick G32D 9.0L WARNING Use only Ssangyong genuine engine oil and filters. Use of non-rec- ommended products could cause damage to the engine. 13-6 SERVICE AND MAINTENANCE Page 6 2006-05-17, ¿ÀÈÄ 1:00...
Page 231: Service And Maintenance
• Use only the Ssangyong genuine engine oil and filter. Oil Consumption : Max. 0.8 Liter per 1,000 km Accordingly, it is necessary for the driver to check frequently the Engine oil oil level and to replenish oil if needed.
Page 232 Engine • Use only the Ssangyong genuine The viscosity should be selected according to outside temperature. Do not engine oil. switch to a different viscosity in the event of brief temperature fluctuations.
Page 233: Diesel Engine (D27Dt)
Park the vehicle on level ground and apply the parking brake. • Replacement: Every 3 years or every 60,000 km Stop the engine and wait until it cools. Ssangyong genuine coolant Diesel Engine (D20DT) 11.5 1. The coolant level should be between the MAX and MIN...
Page 234 Use only the 1. Open the coolant surge tank cap slowly when the engine Ssangyong genuine coolant and anti-freeze. If different types of is cold. At this time, you can hear a “hissing” sound.
Page 235: Air Cleaner
AIR CLEANER Diesel Engine Cleaning Blow the compressed air through the element in the opposite direction to normal air flow to clean the element. Diesel EU: Initial clean: 5,000 km, clean every 15,000 km, replace every 30,000 km (But, shorten the service interval under severe condition) GENERAL: Initial clean: 5,000 km, clean every 10,000 km, replace every 30,000 km...
Page 236: Power Steering Fluid
POWER STEERING FLUID Diesel Engine Gasoline Engine Power steering fluid reservoir Power steering fluid reservoir Check the fluid level on a level ground with the engine turned off. The fluid level should be between the MIN and MAX marks on the reservoir cap gauge. If it drops to or below the MIN mark, refill the reservoir with the specified fluid.
Page 237: Fuel Filter And Priming Pump
D20DT, D27DT FUEL FILTER AND PRIMING PUMP (Without Additional Water Separator) DIESEL ENGINE • Change the fuel filter at every 30,000 km (EU) or 25,000 km Plug opening direction (General) of driving. Plug closing direction • Drain water from the fuel filter whenever replacing the engine oil. Fuel filter •...
Page 238: Fuel Filter And Water Separator (With Additional Water Separator)
D20DT, D27DT FUEL FILTER AND WATER SEPARATOR (With Additional Water Separator) DIESEL ENGINE Fuel filler Priming Pump Operating Conditions Priming 1. If the vehicle has been run out of fuel pump Water 2. After draining water from the fuel filter. separator 3.
Page 239: Fuel Filter
FUEL FILTER • Service Interval Replace every 30,000 km (Draining water from fuel filter: whenever replacing the engine oil) General Replace every 25,000 km (Draining water from fuel filter: whenever replacing the engine oil) Water Separating Function If the water in fuel gets into the engine and the fuel system, it may cause serious damage in the fuel system.
Page 240: Water Separator
WATER SEPARATOR Location: Behind the fuel filter (between the fuel filter and the dash panel) in the engine compartment (engine intake side) Draining the Water from Water Separator Drain the water from the water separator whenever replac- ing the engine oil. After draining the water, press the priming pump until it be- comes rigid.
Page 241: Fuel Filter (For Gasoline)
Replace the fuel filter according to the specified maintemamce schedule. Service Interval Every 100,000 km (if using poor quality Replacement of fuel, replace every 30,000 km) CAUTION Replace with a Ssangyong genuine part with specified intervals. 13-17 SERVICE AND MAINTENANCE Page 17 2006-05-17, ¿ÀÈÄ 1:00...
Page 242: Brake And Clutch Fluid (With M/T)
• The fluid gradually decreases according to brake pad wear. A sudden drop of the fluid level may indicate a leak in the system. In this case, have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center.
Page 243: Washer Fluid
WASHER FLUID TOP UP WASHER FLUID Diesel Engine Frequently check the washer fluid level and add the speci- fied product as needed. In winter, use only the specified washer liquid for winter season. WARNING • The washer fluid includes flammable materials to prevent freezing.
Page 244: Battery
If the warning light comes on while driving, turn off all unnec- essary electrical devices and have the system checked by a Ssangyong Dealer or Ssangyong Authorized Service Center. Battery Maintenance • Make sure the terminal connections are securely tightened.
Page 245 WARNING CAUTION • The battery has acid that can burn you. And its gas can explode. • If you disconnect the battery terminal when the engine is You can get serious injuries if you are not careful. Keep naked running, electrical systems could be damaged. flames, sparks and smoking items away from the battery.
Page 246: Fuse And Relay Box
• Always replace a specified fuse with the same rating. • If a newly inserted fuse blows again after a short time, have the electrical system checked and repaired by a Ssangyong Dealer or Ssangyong Authorized Service Center. Interior Fuse and Relay Box...
Page 247: How To Check And Replace Fuse
HOW TO CHECK AND REPLACE FUSE Higher amperage Specified amperage Normal Open 1. Turn off all electrical systems and remove the ignition key WARNING from the key cylinder. • The use of anything other than the specified fuse could cause 2.
Page 248 ENGINE ROOM FUSE BOX LABEL SPARE SPARE SPARE SPARE SPARE 7.5 A CABIN CABIN POWER F/BOX ABS/ESP F/BOX POWER ALTERNATOR WINDOW (B+POWER) (B+POWER1) KEY 1 WINDOW PTC: 150A GSL, FFH: 125A RR DEFOGGER ABS/ESP MIRROR FOLD' G HAZARD HEAD LAMP RLY 18 7.5A HEAD LAMP...
Page 249 INTERIOR FUSE BOX LABEL (DRIVER’S SIDE) 13-25 SERVICE AND MAINTENANCE Page 25 2006-05-17, ¿ÀÈÄ 1:00...
Page 250 INTERIOR FUSE BOX LABEL (PASSENGER’S SIDE) SPARE SPARE *DSL SPARE HAZARD LAMP ENG ECU SPARE SPARE PASS P/SEAT SPARE SPARE SPARE DSP & AMP *DSL NAVIGATION ENG ECU HAZARD LAMP BLOWER AUDIO UNIT 7.5A *DSL SPARE ENG ECU 7.5A *GSL *GSL SHIFT SPARE...
Page 251: Tire
TIRE TIRE INFLATION PRESSURE Under Proper Over inflation inflation inflation Tire Pressure CAUTION • Maintaining the specified tire pressure is essential for comfort- Driving tires Spare tire able riding, driving safety, and long tire life. Incorrect inflation pressures will increase tire wear and will impair safety, vehicle 30 psi (2.06 bar) 60 psi (4.13 bar) handling, comfortable driving and fuel economy.
Page 252: Tire Rotation
WARNING • Check tires regularly for any damage (foreign objects, punctures, • Be sure to replace and rotate the tires at a Ssangyong Autho- cuts, cracks, bulges in side walls) and replace if necessary. rized Service Center or professional tire shops.
Page 253: Tire Chain
Keep the removed snow tires in a cool and shady place. Be careful not objects during driving, have it checked by a to contact them with any oil, grease, or fuel. Ssangyong Dealer or Ssangyong Authorized Ser- vice Center. • The use of tire sizes other than the specified sizes...
Page 254: Wiper Blade Replacement
WIPER BLADE REPLACEMENT 1. Lift the wiper arm up from the 2. Press the safety button ( ). 3. Slide the blade down and remove windshield. it from the arm. 4. Install a new blade. • The tailgate wiper blade can be re- 5.
Page 255: Spark Plugs (For Gasoline)
GASOLINE ENGINE SPARK PLUGS (FOR GASOLINE) SPARK PLUGS Spark plugs should be inspected periodically for carbon deposits. When carbon accumulates on a spark plug, a strong spark may not be produced. If necessary, clean the electrodes with a fine wire brush and carefully scrape the carbon off the insulator with a small file.
Page 256: Drive Belt
DRIVE BELT TRANSFER CASE OIL Service Interval, Specification and Capacity Inspect every 15,000 km Service Change every 60,000 km interval (frequent check of oil leak) ® Specification ATF DEXRON Direct Injection Part time Capacity Diesel Engine, Gasoline Engine Gasoline Engine You do not need extra tension adjustment, but check belt for wear or tension by pushing the belt and replace if necessary.
Page 257: Do-It-Yourself Operation
• Use only the genuine Ssangyong oils and fluids. • When working with the battery or fuel related components, • Do not allow oils and coolant to make contact with skin or painted always stop the engine and do not smoke.
Page 258: Scheduled Maintenance Services (Diesel Engine)
* Use only approved SCHEDULED MAINTENANCE SERVICES (DIESEL ENGINE) Ssangyong genuine parts. Maintenance service and record retention are the owner’s responsibility. You should retain evidence that proper maintenance has been performed on your vehicle in accordance with the scheduled maintenance service chart.
Page 259: Automatic Transmission Fluid
* Use only approved Ssangyong genuine parts. * EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.) Kilometers (miles) or time in months, whichever comes first MAINTENANCE x1,000 km INTERVAL MAINTENANCE x1,000 miles...
Page 260 * Use only approved Ssangyong genuine parts. * EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.) Kilometers (miles) or time in months, whichever comes first MAINTENANCE x1,000 km INTERVAL MAINTENANCE x1,000 miles...
Page 261: Scheduled Maintenance Services (Gasoline Engine)
* Use only approved SCHEDULED MAINTENANCE SERVICES (GASOLINE ENGINE) Ssangyong genuine parts. Maintenance service and record retention are the owner’s responsibility. You should retain evidence that proper maintenance has been performed on your vehicle in accordance with the scheduled maintenance service chart.
Page 262 * Use only approved Ssangyong genuine parts. * EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.) Kilometers (miles) or time in months, whichever comes first MAINTENANCE x1,000 km INTERVAL MAINTENANCE x1,000 miles...
Page 263 * Use only approved Ssangyong genuine parts. * EU Countries: Only countries that belong to EU. (It does not apply to all countries in EU.) Kilometers (miles) or time in months, whichever comes first MAINTENANCE x1,000 km INTERVAL MAINTENANCE x1,000 miles...
Page 264 MEMO ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Page 40 2006-05-17, ¿ÀÈÄ 1:00...
Page 265 Lamp TABLE OF CONTENTS Bulb Specifications and Functional Check ............14-2 Location of Exterior Lamps ...... 14-3 Interior Lamps .......... 14-11 Page 1 2006-05-17, ¿ÀÈÄ 1:00...
Page 266: Bulb Specifications And Functional Check
Luggage lamp cloth. ← Door courtesy lamp • Never try to adjust the headlamp aiming angle. It should be done by a qualified technician in a Ssangyong Dealer or Ssangyong Au- thorized Service Center. 14-2 LAMP Page 2 2006-05-17, ¿ÀÈÄ 1:00...
Page 267: Location Of Exterior Lamps
LOCATION OF EXTERIOR LAMPS High mounted stop lamp Front fog Back-up lamp Side repeater light Headlamp Rear Combination Lamp Tail lamp Turn signal Tail lamp/ lamp Stop lamp * Rear fog lamp: Mandatory Turn signal lamp High beam option where required by Low beam regulation 14-3...
Page 268: Removing Headlamp Housing
Headlamp high beam WARNING For safe driving, do not adjust the headlamp aiming by yourself. It should be done by a qualified technician in a Ssangyong Dealer or Ssangyong Authorized Service Center. 14-4 LAMP Page 4 2006-05-17, ¿ÀÈÄ 1:00...
Page 269: Lamps 14
HEADLAMP TURN SIGNAL LAMP 1. Remove the headlamp cover from the removed headlamp 1. Remove the turn signal lamp connector from the removed housing. headlamp housing. 2. Release the fixing clip. 2. Push down and turn the bulb to remove. 3.
Page 270: Front Fog Light
Ssangyong dealer or authorized be done by a Ssangyong dealer or authorized 2. Remove the front fog light connec- service operation.
Page 271: Side Repeater
SIDE REPEATER 1. Remove the ignition key from the key cylinder. Side repeater 2. Pull the lamp housing out while pushing it rearward. 3. Disconnect the connector. 4. Remove the bulb housing. 5. Remove the bulb from the housing. 6. Replace it with a new one. 7.
Page 272: Rear Combination Lamp
REAR COMBINATION LAMP 1. Remove the ignition key from the key cylinder. 2. Disconnect the two mounting bolts from the rear combination lamp. 3. Remove the rear combination lamp from the body. Tail lamp / 4. Turn the bulb housing to remove. Rear combination lamp Stop lamp Turn signal...
Page 273 TAILGATE COMBINATION LAMP 1. Remove the ignition key from the key cylinder. 2. Remove the bolt cover on the tail- gate and remove the three bolts. 3. Remove the rear combination lamp housing while pushing it rearward. Tail lamp Tailgate combination lamp 4.
Page 274: License Plate Lamp
LICENSE PLATE LAMP 1. Remove the ignition key from the key cylinder. 2. To take out the license plate light assembly, remove the two fasten- ing screws on the license plate light and push the assembly downward. 3. Remove the lamp housing by turn- ing the connector.
Page 275: Interior Lamps
INTERIOR LAMPS FRONT ROOM LAMP CENTER ROOM AND LUGGAGE ROOM LAMPS 1. Remove the ignition key from the key cylinder. 1. Remove the ignition key from the key cylinder. 2. Cover the tip of a flat blade screwdriver with a cloth and 2.
Page 276: Glove Box Lamp
GLOVE BOX LAMP DOOR COURTESY LAMP 1. Remove the ignition key from the key cylinder. 1. Remove the ignition key from the key cylinder. 2. Open the cover as shown in the figure. 2. Cover the tip of a flat blade screwdriver with a cloth and insert the tip into a lamp cover slot.
Page 277 Vehicle Care TABLE OF CONTENTS Vehicle Care ..........15-2 Running-In Period ......... 15-2 Cleaning Agents ..........15-2 Care and Cleaning of the Interior ....15-3 Glass Surfaces ..........15-4 Care and Cleaning of the Exterior ....15-4 Corrosion Protection ........15-5 Important Safety Instructions ....
Page 278: Running-In Period
VEHICLE CARE RUNNING-IN PERIOD CLEANING AGENTS Follow the manufacturer’s advice whenever cleaning agents or other chemicals are used for the inside or the outside of the vehicle. Some cleaners may be poisonous or flammable, and improper use may cause personal injury or damage. When cleaning the inside or outside of the vehicle, do not use volatile cleaning solvents such as: acetone, lacquer thinners, enamel reducers, nail polish removers;...
Page 279: Care And Cleaning Of The Interior
CARE AND CLEANING OF THE INTERIOR Seat Belt Care • Keep belts clean and dry. • Clean seat belts only with mild soap and lukewarm water. • Do not bleach or dye belts since this may severely weaken them. With the use of modern trim materials, it is very important that you use proper cleaning techniques and cleaners.
Page 280: Glass Surfaces
Ssangyong vehicles are designed to operate under normal equivalent non abrasive cleaner. Your windshield is clean if environmental conditions and to withstand the natural beads do not form when rinsing with water.
Page 281: Corrosion Protection
CORROSION PROTECTION Protecting Exterior Bright Metal Parts Your car was designed to resist corrosion. When it was built, special and protective finishes were used on most parts of Bright metal parts should be cleaned regularly to keep their your car to help maintain a good appearance, strength and luster.
Page 282: Vehicle Care
Therefore you should use only a filling station or a should be repaired promptly. Bare metal will corrode quickly Ssangyong Distributor who has oil separator equipment in the car and may develop into a major repair expense. Minor chips wash bay.
Page 283: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS BEFORE DRIVING Checking the Driving Conditions: For safe and comfortable driving, check each part of the vehicle before driving your vehicle. • Adjustment of the rearview mirror • Applying the brake and releasing the parking brake CAUTION •...
Page 284 Always Using Seat belt Do Not Leave a Child Alone in the Vehicle Everyone in your vehicle needs to be buckled up at all When left alone in the car, a child might unintentionally start times. the engine, cause a fire, or cause another accident. WARNING WARNING •...
Page 285: On The Road
(steering wheel shakes up and down / the engine off. right and left / in circular motion), immediately visit the nearest Ssangyong Dealer or Ssangyong Authorized Service Center to CAUTION check and repair steering and suspension parts.
Page 286 Moving Your Vehicle Only After Starting the Engine When Parking or Stopping in An Enclosed Place Move your vehicle only after having started the engine. When parking or stopping in an enclosed place, turn off the engine. WARNING WARNING Driving the vehicle on a downhill using the downgrade slope without running the engine might cause an accident.
Page 287 • The warranty does not cover problems caused by using non- Ssangyong genuine parts. Always Putting Out Cigarettes • You can distinguish an authentic Ssangyong genuine part by its • Make sure you have put out all cigarettes and matches hologram.
Page 288 Driving on a Snowy or Icy Road Driving on Unpaved and Mountain Roads • Shift to the lowest possible gear and drive slowly. • Before driving, check road conditions such as if the road suddenly ends, or if there is enough space for a U-turn in •...
Page 289 Important things to remember when going Driving On Hill Roads through water Position the gearshift lever in accordance with the road • If the engine stops while you are going through water, do conditions. not try to restart. Get your vehicle towed. •...
Page 290: Prohibition Of Unauthorized Modifications
Modification of Fuses and Circuits • Always respect the speed limit and refrain from speeding. Always use the Ssangyong genuine fuses of the specified • Allow for a safe following distance, avoid sudden steering capacity and do not alter or modify your vehicle’s circuits. It movements.
Page 291: Index 16
Index Page 1 2006-05-17, ¿ÀÈÄ 1:01...
Page 292 4-wheel drive switch* ......4-24 Cautions when a tire is flat ....12-4 4wd indicators (part time T/C only) ..5-14 Cautions when changing the tire ..12-13 EBD warning light, engine hood open Cautions when using 4-wheel drive mode warning light ........
Page 293 HDC (hill descent control) switch* ..4-20 Light switch .......... 4-4 Rain sensing wiper* ......4-10 Heated glass switch ......4-22 Location of exterior lamps ....14-3 Rear armrest / assist grip and coat hook Heater / air conditioner system .... 9-2 Locations in engine compartment ..
Page 294 Shift lever lock release and safety mode reset ..........12-17 Vehicle care ........15-2 Spare tire and winter tire ....13-29 Vehicle identification ......0-8 Spark plugs (for gasoline) ....13-31 Specifications ........0-4 SSPS warning light ......5-9 Warning and caution ......7-11 Starting the engine and driving off the Warning triangle* ......
Page 295 150-3, CHILGOI-DONG, PYUNGTAEK-SI GYEONGGI-DO, 459-711 KOREA TELEPHONE : 82-31-610-2740 FACSIMILE : 82-31-610-3762 NOTE:All rights reserved. Printed in SSANGYONG Motor Co., Ltd. No part of this book may be used or reproduced without the written permission of Overseas A/S Team. Page 5...
Page 296 EDITION HISTORY CODE NO. PRINTING DATE MODEL YEAR REMARKS RKY1-6OM0E-6C-500A Mar, 2006 2006 RKY1-6OM0E-6C-500B Mar, 2006 2006 Page 6 2006-05-17, ¿ÀÈÄ 1:01...

SSANGYONG KYRON 2006 Owner's Manual

Recommended Fluids and Lubricants

Safety Precautions

Ignition Key, Remote Control Key

Opening and Closing

Interior Switches

Instrument Cluster

Transmission and Brake System

7 0 Seats 1 2 3

Seat Belt and Air Bag

Ventilation, Heating, Air Conditioning 9

Convenience Devices

In Case of Emergency

Service and Maintenance

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SSANGYONG KYRON 2006

Summary of Contents for SSANGYONG KYRON 2006
