ABS/ESP Sensor Value
No Content
1 Wheel Speed FR
2 Wheel Speed FL
3 Wheel Speed RR
4 Wheel Speed RL
5 Battery Voltage
6 Longitudinal Acceleration Sensor
7 Lateral Aceleration Sensor
8 Yaw Rate Sensor
9 Steering Wheel Angle sensor
10 Pressure Sensor (Primary)
11 Pressure Sensor (Secondary)
12 EBD Control
13 BTCS Control
14 Engine TCS Control
15 ESP Control
16 ESP/TCS OFF Switch
17 ABS Control
18 Stop Lamp Switch
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Unit
1 km/h
1 km/h
1 km/h
1 km/h
0.1V
0.01 g-: Straight ahead
0.01 g +: Left Turn
0.5 deg/s +: Left Turn
5 deg +: Left Turn
1 bar
1 bar
Operation / Non-operation
Operation / Non-operation
Operation / Non-operation
Operation / Non-operation
ON / OFF
Operation / Non-operation
ON / OFF
4890
ESP ABS
O O
O O
O O
O O
O O
O O
O X (Fixed Value: 0)
O X (Fixed Value: 0)
O X (Fixed Value: 0)
O X (Fixed Value: 0)
O X (Fixed Value: 0)
O O
O X
O
X
O X
O X
O O
O O
(O: Applied, X: N/A)
ABS/ESP SYSTEM
