5. OPERATION MODE OF RAIN SENSING WIPER SYSTEM

Driver Switch Positions
MIST
(Transmits the manual operation
mode signal to sensor)
OFF
(Transmits the manual operation
mode signal to sensor)
AUTO 1
(low sensitivity)
AUTO 2
(low/med sensitivity)
AUTO 3
(medium sensitivity)
AUTO 4
(med/hi sensitivity)
AUTO 5
(high sensitivity)
LOW SPEED
(transmits the manual operation
mode signal to sensor)
HI SPEED
(transmits the manual operation mode
signal to sensor)
1. Rain detected headlamp: If it rains heavy which requires the highest INT speed, the headlamps are turned on
automatically.
2. Night detected wiping: When the auto light control turns on the headlamps and the rain sensor detects the
rain, the wiper sensitivity is automatically increased by one level. (i.e. the AUTO wiper switch is at the 3rd level,
but the wiper operates at the 4th level.)
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
As long as the switch is in MIST position, the wiper motor operates in
low speed. The wiper blade returns to parking position if the switch re-
turns to the original position. The rain sensor ignores inputs during park-
ing signal periods.
The wiper motor rotates in low speed until it returns to parking position.
When the system is in manual mode, the sensitivity of sensor will be
set to 2 (AUTO 2) internally. By doing so, immediate wiping with proper
intervals is possible when a driver sets the system from OFF to AUTO.
Auto delay/auto speed control. Low sensitivity against rains on windshield.
SLOW
When the switch is in AUTO position, the sensor transmits the wiping
request signal to STICS.
Auto delay/auto speed control. Low/medium sensitivity against rains on
windshield.
Auto delay/auto speed control. Medium sensitivity against rains on
windshield.
Auto delay/auto speed control. Medium/high sensitivity against rains on
windshield.
Auto delay/auto speed control. High sensitivity against rains on
FAST
windshield.
The wiper motor rotates continuously in low speed of approx. 45 rev./
minute at B+=13.5V (in the normal battery voltage). The rain sensor
operations are same as in MIST.
The wiper motor rotates continuously in high speed of approx. 70 rev./
minute at B+=13.5V (in the normal battery voltage). The rain sensor
operations are same as in MIST.
Operation Mode
RAIN SENSOR UNIT (WITH AUTO RIGHT SENSOR)
