Actuator
ABS/ESP SYSTEM
KYRON SM - 2005.09
ACTUATOR TEST
ACTUATOR TEST
1. FRONT/LEFT INLET VALVE
2. FRONT/LEFT OUTLET VALVE
3. FRONT/RIGHT INLET VALVE
4. FRONT/RIGHT OUTLET VALVE
5. REAR(ESP: REAR/LEFT) INLET VALVE
6. REAR(ESP: REAR/LEFT) OUTLET VALVE
7. REAR/RIGHT(Only ESP) INLET VALVE
8. REAR/RIGHT(Only ESP) OUTLET VALVE
9. 1st TCS VALVE(Only ESP)
10. 2nd TCS VALVE(Only ESP)
11. 1st ESV VALVE(Only ESP)
12. 2nd ESV VALVE(Only ESP)
13. PUMP MOTOR
Select one of the above items
FRONT/LEFT INLET VALVE
----------------------------------------------------
ON(ACTIVE): "YES" KEY
OFF(STOP): "NO" KEY
OTHER ITEM : "
----------------------------------------------------
ACTIVE TIME : Max. 10 Sec
CONDITION : IG. ON or IDLE
, "
