4. REAR WINDOW REGULATOR

Preceding Work: Disconnect the negative battery cable.
1. Lower the window. Unscrew the mounting screw and bolts
from and remove the guide channel and windshield dam.
Mounting screw
3. Unscrew the window motor nut (A) and guide rail nut (B)
and remove the window regulator from the door.
BODY EXTERIOR
KYRON SM - 2005.09
2. Disconnect the motor connector and un-
screw the mounting screws from the win-
dow guide to remove the rear window.
