Sensor Initialzation (ABS & ESP)
SENSOR INITIALIZE (Only ESP)
1] LONGITUDINAL SENSOR
(4WD only)
2] LATERAL SENSOR
3] PRESSURE SENSOR
4] ABOVE 1,2,3 ALL SENSOR
Select one of the above items
Steering wheel angle sensor
The steering wheel angle sensor automatically searches for a center position when the vehicle is driving straight
forward with 20 km/h of driving speed (no additional diagnostic menu).
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
SENSOR INITIALIZE
LONGITUDINAL ACCEL SENSOR(4WD only)
DO YOU START INITIALIZE ? (Yes/No)
CONDITION :
- ENGINE IS NOT RUNNING.
- VEHICLE STATUS IS FLAT.
- DO NOT PUT THE BRAKE PEDAL.
PROCEDURE :
MUST BE FOLLOW THE ABOVE CONDITION.
IF YOU START "INITIALZE SENSOR"
ADAPT TO AUTOMATIC.
Initialize both the primary and secondary pres-
sure sensors when initializing a pressure sensor.
