8. DIAGNOSTIC CONNECTOR

Connection Between Scan-100 and Diagnostic Connector
Scan-100
CAN module
Additional Devices of Scan-100
(Diagnosis: EAS, EPB Only)
CAN module
ELECTRIC SYSTEM
KYRON SM - 2005.09
Diagnostic connector
Additional cable for CAN module
Connection of Scan-100
(Including CAN Module and Additional Cable)
CAN module
connecting cable
