B Pillar Trim
Remove the front and rear scuff trims (A) and
remove the lower B pillar.
B Pillar Assembly
A Pillar Assembly
D Pillar
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
Unscrew the upper screw and remove the up-
per B pillar.
A Pillar
Remove the door weather strip and unscrew the mounting
screws to remove the A pillar.
C Pillar
Remove the seat belt and unscrew the mount-
ing screws to remove the C pillar.
Be careful not to damage the pillars and
fasteners.
13
7730
BODY INTERIOR
KYRON SM - 2005.09
