2. CONFIGURATION OF ABS SYSTEM

The following figure shows the basic system components of the ABS. This system consists of HECU (valve body
and ECU integrated type), front wheel speed sensor, and rear wheel speed sensor.
Front Wheel Speed Sensor Rear Wheel Speed Sensor
(for 4WD)
HECU (Valve body and ECU
integrated type)
Rear wheel
speed sensor
(RR)
Valve body
Front wheel
speed
sensor (FR)
Rear wheel speed
ABS HECU
sensor (RL)
Front wheel speed sensor (FL)
B: Plunger C: Can bushing
ABS warning lamp
Motor pump
ABS/ESP SYSTEM
