5. Remove the mounting screws (3 EA) from the steering will steering wheel sensor and the multifunction switch
(4 EA) at this moment, disconnect the connectors.
Steering wheel
angular sensor
connector
6. Remove the steering wheel angular sensor from the re-
moved multifunction switch assembly.
Light switch
SWITCHES / ELECTRIC DEVICES
KYRON SM - 2005.09
Multifunction
switch connector
Multifunction switch
Light switch
Steering wheel
angular sensor
Turn signal & wiper switch
Turn signal &
wiper switch
