5. Remove the upper arm between frame and the axle.
A. Unscrew upper arm mounting bolt/nut
(22 mm) on axle.
Tightening torque
NOTICE
• The fuel tank should be removed before removing the rear left bolts (upper arm and lower arm).
SUSPENSION
KYRON SM - 2005.09
B. Unscrew upper arm mounting bolt/nut
150 ~ 180 Nm
(22 mm) on frame.
Tightening torque
EFFECTIVE DATE
150 ~ 180 Nm
