Oil Temperature Sensor
Function
The oil temperature sensor is installed in the hydraulic control unit and is connected in series with the starter lock-out
contact.
This means that the temperature signal is transferred to TCU when the starter lock-out contact is closed.
The oil temperature has a considerable effect on the shifting time and therefore the shift quality. By measuring the oil
temperature, shift operations can be optimized in all temperature ranges.
Circuit Diagram
Start lock out switch
Oil temperature sensor
AUTO TRANSMISSION
KYRON SM - 2005.09
Oil temperature sensor
B7 (34)
AD converter
B8 (33)
