2. REMOVAL AND INSTALLATION OF IWE (INTEGRATED WHEEL END)

Wheel Speed Sensor
Preceding Work: Disconnect the negative battery cable and remove the tires.
Note: Wheel speed sensor location
Front side (2WD) Rear side (5-link type) Rear side (IRS type)
1. Unscrew the two bolts (19 mm) and set the removed brake caliper on the frame.
Tightening torque:
(85 ~ 105 Nm)
2. Unscrew the two screws and remove the brake disc.
