SSANGYONG Kyron Repair Manual page 835

31
8932
TV Antenna Module (LH/RH) Radio Antenna Module
Preceding Work: Remove the rear quarter up- Preceding Works:
per panel.
1. Remove the luggage room lamp assembly.
2. Remove the third row and fourth row seats.
3. Remove the rear quarter upper and lower trims.
4. Remove the rear headlining.
Radio antenna module
TV antenna module
TV antenna module
TV antenna connection at tuner Radio antenna connection at tuner
AV SYSTEM
CHANGED BY
EFFECTIVE DATE KYRON SM - 2005.09
AFFECTED VIN
